Scissor lift table TC150

hydraulicfoot-operatedmobile

Description

• Heavy duty design for professional applications.
• Manufactured to work both indoors and outdoors.
• Easy to lift by foot-operated hydraulic pump.
• Equipped with a slot on the loading platform that permits taking the rear wheel off.
• Operator safety ensured by an overload valve and mechanical stopping devices; lifting and lowering can be stopped at any position without affecting stability and safety conditions.

Product data
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Platform Height mm(in.) | Max. Platform Height mm(in.) | Platform Size mm(in.) | Net Weight kg(lb.)
1311901 | TC150 | 150 (330) | 145 (5.7) | 1070 (42.1) | 1400×470 (55.1×18.5) | 100 (220)

Technical specifications

• i-LIFT NO.: 1311901
• Model: TC150
• Capacity: 150 kg (330 lb)
• Minimum platform height: 145 mm (5.7 in)
• Maximum platform height: 1070 mm (42.1 in)
• Platform size: 1400×470 mm (55.1×18.5 in)
• Net weight: 100 kg (220 lb)
• Foot-operated hydraulic pump
• Platform rear-wheel slot for wheel removal
• Overload valve and mechanical stopping devices for safety
