Mobile scissor lift BS50LA

wheeledwheel-mountedfor industrial applications

Product Overview
Mobile lift table designed for handling large-size materials in industrial environments. Adjustable table height and mounted on Φ150 mm (6 in) front load and steering wheels for on-site mobility.

Models and Specifications

• BS50LA — Capacity: 500 kg (1,102 lb); Table size: 1525×620 mm (60×24.4); Height (Min/Max): 400/1100 mm (15.7/43.3); Front load wheel: Φ150 mm (6 in); Steering wheel: Φ150 mm (6 in)
• BS50LB — Capacity: 500 kg (1,102 lb); Table size: 1200×800 mm (47.2×31.5); Height (Min/Max): 370/1190 mm (14.6/46.9); Front load wheel: Φ150 mm (6 in); Steering wheel: Φ150 mm (6 in)
• BS100L — Capacity: 1000 kg (2,205 lb); Table size: 1200×800 mm (47.2×31.5); Height (Min/Max): 425/1225 mm (16.7/48.2); Front load wheel: Φ150 mm (6 in); Steering wheel: Φ150 mm (6 in)
• ES50LA — Capacity: 500 kg (1,102 lb); Table size: 1525×620 mm (60×24.4); Height (Min/Max): 440/1150 mm (17.3/42.3); Front load wheel: Φ150 mm (6 in); Steering wheel: Φ150 mm (6 in)
• ES50LB — Capacity: 500 kg (1,102 lb); Table size: 1200×800 mm (47.2×31.5); Height (Min/Max): 430/1220 mm (17/48); Front load wheel: Φ150 mm (6 in); Steering wheel: Φ150 mm (6 in)
• ES100L — Capacity: 1000 kg (2,205 lb); Table size: 1200×800 mm (47.2×31.5); Height (Min/Max): 430/1220 mm (17/48); Front load wheel: Φ150 mm (6 in); Steering wheel: Φ150 mm (6 in)

Features / Technical specifications

• Series: BSL/ESL Series (Mobile Lift Table)
• Purpose: handling and lifting large-size materials
• Available models: BS50LA, BS50LB, BS100L, ES50LA, ES50LB, ES100L
• Capacities: 500 kg (1,102 lb) and 1000 kg (2,205 lb) depending on model
• Table sizes: 1525×620 mm (60×24.4) or 1200×800 mm (47.2×31.5)
• Adjustable table height: model-dependent (examples: 400/1100 mm, 370/1190 mm, 425/1225 mm, 440/1150 mm, 430/1220 mm)
• Wheels: Front load wheel Φ150 mm (6 in); Steering wheel Φ150 mm (6 in)
