Mobile scissor lift ES series

wheeledwheel-mountedelectric

Product overview

• Robust structure with reduced weight for easy maneuvering in industrial environments.
• Two independent brakes to improve parking stability and operator safety.
• European-made DC power unit, 800 W.
• High-capacity batteries: single-scissor models 54Ah/12V; double-scissor models 80Ah/12V.
• Integrated automatic battery charger for on-site recharging.
• 150 mm diameter wheels and rollers for smooth movement on workshop floors.
• Handle height: 1185 mm for ergonomic control.

Models and specifications (table)
i-LIFT NO. | Model No. | Capacity kg(lb.) | Table Size mm(in.) | Table Height (Min./Max.) mm(in.) | Front Load Wheel mm(in.) | Steering Wheel mm(in.)
1310501 | ES30 | 300 (660) | 1010×520 (39.8×20.5) | 450 / 950 (18.9 / 37.4) | 150 (6) | 150 (6)
1310502 | ES50 | 500 (1100) | 1010×520 (39.8×20.5) | 450 / 950 (18.9 / 37.4) | 150 (6) | 150 (6)
1310503 | ES75 | 750 (1650) | 1010×520 (39.8×20.5) | 450 / 950 (18.9 / 37.4) | 150 (6) | 150 (6)
1310504 | ES100 | 1000 (2200)| 1010×520 (39.8×20.5) | 480 / 950 (18.9 / 37.4) | 150 (6) | 150 (6)
1310505 | ES30D | 300 (660) | 1010×520 (39.8×20.5) | 495 / 1600 (19.5 / 63.0) | 150 (6) | 150 (6)
1310506 | ES50D | 500 (1100) | 1010×520 (39.8×20.5) | 495 / 1618 (19.5 / 63.7) | 150 (6) | 150 (6)
1310507 | ES80D | 800 (1760) | 1010×520 (39.8×20.5) | 510 / 1440 (20.1 / 56.7) | 150 (6) | 150 (6)

Technical features / specifications

• Series name: ES series (Mobile Lift Table).
• Power unit: DC 800 W (European-made).
• Batteries: single-scissor 54Ah/12V; double-scissor 80Ah/12V.
• Includes automatic battery charger for maintenance-free charging.
• Dual braking system for improved operational safety.
• Wheel & roller diameter: 150 mm (6 in) for both front load and steering wheels.
• Handle height: 1185 mm for operator ergonomics.
• Standard table size across models: 1010 × 520 mm (39.8 × 20.5 in).
• Capacities and lift ranges vary by model (see table above).
