Scissor lift table SJZ series

electricmobile

Product Overview
The SJZ series scissor aerial work platforms are self-propelled scissor lifts with integrated drive and turning mechanisms, enabling relocation and positioning without external towing or an external electrical supply. They offer on-board maneuverability for faster, safer high-access operations in industrial environments such as maintenance, installation and assembly tasks.

Model Variants

• i-LIFT NO. 2430301 | Model SJZ0306 — Capacity: 300 kg (660 lb); Min. platform height: 1100 mm (43.3 in); Max. platform height: 6000 mm (236.2 in); Platform size: 1800×1000 mm (70.9×39.4 in); Elevating time: 49 s.
• i-LIFT NO. 2430302 | Model SJZ0506 — Capacity: 500 kg (1100 lb); Min. platform height: 1100 mm (43.3 in); Max. platform height: 6000 mm (236.2 in); Platform size: 1800×1000 mm (70.9×39.4 in); Elevating time: 54 s.
• i-LIFT NO. 2430303 | Model SJZ0309 — Capacity: 300 kg (660 lb); Min. platform height: 1350 mm (53.1 in); Max. platform height: 9000 mm (354.3 in); Platform size: 1900×1000 mm (74.8×39.4 in); Elevating time: 75 s.
• i-LIFT NO. 2430304 | Model SJZ0509 — Capacity: 500 kg (1100 lb); Min. platform height: 1600 mm (63.0 in); Max. platform height: 9000 mm (354.3 in); Platform size: 1900×1000 mm (74.8×39.4 in); Elevating time: 82 s.
• i-LIFT NO. 2430305 | Model SJZ0311 — Capacity: 300 kg (660 lb); Min. platform height: 1600 mm (63.0 in); Max. platform height: 11000 mm (433.1 in); Platform size: 2100×1150 mm (82.7×45.3 in); Elevating time: 95 s.
• i-LIFT NO. 2430306 | Model SJZ0511 — Capacity: 500 kg (1100 lb); Min. platform height: 1600 mm (63.0 in); Max. platform height: 11000 mm (433.1 in); Platform size: 2100×1150 mm (82.7×45.3 in); Elevating time: 98 s.

Technical characteristics / specifications

• Self-propelled drive and turning drive provide on-board maneuverability without external manpower or towing.
• No external electrical power required for relocation (self-propelled movement).
• Engineered for high-access industrial tasks with focus on operational efficiency and safety.
• Available platform sizes: 1800×1000 mm, 1900×1000 mm, 2100×1150 mm (depending on model).
• Available maximum platform heights: 6000 mm, 9000 mm, 11000 mm (model dependent).
• Available capacities: 300 kg (660 lb) and 500 kg (1100 lb).
• Minimum platform heights: 1100 mm, 1350 mm, 1600 mm (depending on model).
• Approximate elevating times by model: 49 s, 54 s, 75 s, 82 s, 95 s, 98 s.
• Each unit is identified by i-LIFT NO. and Model No. as listed above.
