Needle valve MCJ-000XX-3-1335G4Y
electrically-actuatedmanualelectric

Needle valve - MCJ-000XX-3-1335G4Y - Rotork - electrically-actuated / manual / electric
Needle valve - MCJ-000XX-3-1335G4Y - Rotork - electrically-actuated / manual / electric
Add to favorites
Compare this product
Go to the Rotork website for more information

Characteristics

Type
needle
Operation
electrically-actuated, manual, electric
Function
metering
Body
threaded
Applications
for air conditioning, process, for industrial applications
Material
stainless steel
Other characteristics
with operating handle, with actuator, quick-connect, with connection, with threaded connection
DN

Max.: 6.35 mm
(0.25 in)

Min.: 6.35 mm
(0.25 in)

Pressure

Max.: 344.7 bar
(5,000 psi)

Min.: 344.7 bar
(5,000 psi)

Description

Product overview
Compact metering valve 1335G4Y by Hoke for precise flow regulation. Constructed in Stainless Steel 316 with a 1/4 in. Gyrolok connection, 0.25 line size, Cv 0.01 and rated to 5000 PSI. Suitable for process control, instrumentation and hydraulic applications requiring fine metering and high-pressure service.

Enclosures
  • Standard Aluminum enclosure
  • Stainless-Steel enclosure
  • Class I Div I Groups B, C, D (CSA and IECEx rated)
  • Stainless-Steel Class I Div I Groups B, C, D (CSA and IECEx rated)
  • IP68 enclosures available

Control settings
  • Analog (4-20 mA or 1-5 V)
  • Modbus (RS485)
  • TTL input 0 V (pull to ground) variable positioning

Feedback options
  • None
  • 4-20 mA feedback

Other features
  • Manual override
  • 110-240 VAC power
  • Battery backup (min. 24 VDC power required)
  • Isolated input
  • Prewired Turck M12 connector with 20 ft cable

Technical specifications
  • Valve: 1335G4Y
  • Manufacturer: Hoke
  • Type: Metering valve
  • Material: Stainless Steel 316
  • Connection: 1/4 in. Gyrolok
  • Line size: 0.25
  • CV: 0.01
  • Pressure rating: 5000 PSI
  • Enclosure options: Aluminum, Stainless Steel, Class I Div I (CSA & IECEx), IP68 available
  • Control interfaces: Analog (4-20 mA / 1-5 V), Modbus (RS485), TTL input
  • Feedback: None or 4-20 mA
  • Power: 110-240 VAC; battery backup requires min. 24 VDC
  • Additional: Manual override; isolated input; prewired Turck M12 connector with 20 ft cable
