Electrically-operated valve MCJ-000XX-3-1345G4Y
electrically-actuatedelectricmetering

Electrically-operated valve - MCJ-000XX-3-1345G4Y - Rotork - electrically-actuated / electric / metering
Electrically-operated valve - MCJ-000XX-3-1345G4Y - Rotork - electrically-actuated / electric / metering
Add to favorites
Compare this product
Go to the Rotork website for more information

Characteristics

Operation
electrically-operated, electrically-actuated, electric
Function
metering
Body
IP68
Material
aluminum, stainless steel
Other characteristics
for hazardous environments, with actuator, actuated, with connection, ATEX
DN

Max.: 3.175 mm
(0.125 in)

Min.: 3.175 mm
(0.125 in)

Pressure

Max.: 344.7 bar
(5,000 psi)

Min.: 0 bar
(0 psi)

Description

Overview
  • Actuated metering valve assembly for precise flow control of liquids and gases.
  • Equipped with Hoke 1345G4Y metering valve and Hanbay M Range actuator/control module.


Key features
  • Valve: Hoke 1345G4Y, metering valve, CV 0.01, line size 0.125 in
  • Material: Stainless Steel 316 (wetted parts)
  • Connection: 1/4 in. Gyrolok
  • Maximum pressure: 5000 PSI


Enclosures
  • Standard Aluminum enclosure
  • Stainless-Steel enclosure
  • Class I Div I Groups B, C, D (CSA and IECEx rated)
  • Stainless-Steel Class I Div I Groups B, C, D (CSA and IECEx rated)
  • IP68 enclosures available*


Control settings
  • Analog (4-20 mA or 1-5 V)
  • Modbus (RS485)
  • TTL input 0 V (pull to ground) for variable positioning


Feedback options
  • None
  • 4-20 mA feedback


Power, connectivity and other features
  • Manual override
  • 110-240 VAC power supply
  • Battery backup (minimum 24 VDC required)
  • Isolated input
  • Prewired Turck M12 connector with 20 ft cable


Technical specifications
  • Model / Series: Hanbay M Range
  • Valve: 1345G4Y (Hoke)
  • Valve type: Metering valve
  • Material: Stainless Steel 316
  • Connection: 1/4 in. Gyrolok
  • Line size: 0.125 in
  • Flow coefficient (CV): 0.01
  • Maximum pressure: 5000 PSI
  • Power supply: 110-240 VAC
  • Battery backup: requires minimum 24 VDC
  • Enclosure options: Standard Aluminum, Stainless-Steel, IP68 available
  • Hazardous area ratings: Class I Div I Groups B, C, D (CSA and IECEx rated)
  • Electrical connector: Prewired Turck M12 with 20 ft cable
