Electric valve actuator MCL-000XX-0-Actuator-only
manualmulti-turnsingle-phase

Electric valve actuator - MCL-000XX-0-Actuator-only - Rotork - manual / multi-turn / single-phase
Electric valve actuator - MCL-000XX-0-Actuator-only - Rotork - manual / multi-turn / single-phase
Add to favorites
Compare this product
Go to the Rotork website for more information

Characteristics

Type
electric, manual
Movement
multi-turn
Phase
single-phase
Protection class
IP68
Other characteristics
modulating, aluminum, with handwheel, stainless steel, bus-capable, analog, with backup battery
Torque

Max.: 200,000,000 Nm
(147,512,429.86 ft.lb)

Min.: 0 Nm
(0 ft.lb)

Voltage

Max.: 240 V

Min.: 110 V

Description

Product overview
Valve type: actuator only
Line size: 0
CV: 0

Enclosures
  • Standard aluminum enclosure
  • Stainless-steel enclosure
  • Class I Div I Groups B, C, D (CSA and IECEx rated)
  • Stainless-steel Class I Div I Groups B, C, D (CSA and IECEx rated)
  • IP68 enclosures available*

Control settings
  • Analog: 4-20 mA or 1-5 V
  • Modbus (RS485)
  • TTL input (0 V pull to ground) for variable positioning

Feedback options
  • None
  • 4-20 mA feedback

Other features
  • Manual override
  • 110-240 VAC power
  • Battery backup (minimum 24 VDC required)
  • Isolated input
  • Prewired Turck M12 connector with 20 ft cable
  • High temperature mounting kit

Technical specifications
  • Series: Hanbay M Range
  • Model / page title: MCL-000XX-0-Actuator-only
  • Valve type: actuator only
  • Line size: 0
  • CV: 0
  • Enclosure options: aluminium, stainless steel, CSA/IECEx Class I Div I (Groups B, C, D), IP68 available
  • Control interfaces: 4-20 mA, 1-5 V, Modbus RS485, TTL input
  • Feedback: optional 4-20 mA or none
  • Power: 110-240 VAC; battery backup requires minimum 24 VDC
  • Connector: prewired Turck M12 with 20 ft cable
  • Additional: manual override and high temperature mounting kit available
