Electric ball valve actuator MCJ-000XX-3-SS-SS4
motorizedquarter-turn90°

Electric ball valve actuator - MCJ-000XX-3-SS-SS4 - Rotork - motorized / quarter-turn / 90°
Electric ball valve actuator - MCJ-000XX-3-SS-SS4 - Rotork - motorized / quarter-turn / 90°
Add to favorites
Compare this product
Go to the Rotork website for more information

Characteristics

Type
electric, motorized
Movement
90°, quarter-turn
Phase
single-phase
Protection class
IP68
Other characteristics
stainless steel, analog, bus-capable, aluminum, with backup battery, for ball valves
Voltage

Min.: 110 V

Max.: 240 V

Pressure

Min.: 0 bar
(0 psi)

Max.: 137.9 bar
(2,000.1 psi)

Rotation angle

90 °

Description

Product
Hanbay Inc. - Hanbay M Range
Model: MCJ-000XX-3-SS-SS4

Valve
  • Valve: SS-SS4
  • Valve manufacturer: Swagelok
  • Valve type: Metering valve
  • Valve material: Stainless-Steel
  • Valve connection: 1/4 in. Compression
  • Line size: 0.25
  • CV: 0.004
  • Pressure: 2000 PSI


Enclosures*
  • Standard Aluminum enclosure
  • Stainless-Steel enclosure
  • Class I Div I Groups B, C, D (CSA and IECEx rated)
  • Stainless-Steel Class I Div I Groups B, C, D (CSA and IECEx rated)
  • IP68 enclosures available*


Control Settings
  • Analog (4-20 mA or 1-5 V)
  • Modbus (RS485)
  • TTL input 0 V (pull to ground) variable positioning


Feedback Options
  • None
  • 4-20 mA feedback


Other Features
  • Manual Override
  • 110-240 VAC Power
  • Battery Backup (min. 24 VDC power required)
  • Isolated Input
  • Prewired Turck M12 connector with 20 ft cable (approx. 6.1 m)


Technical specifications
  • Range: Hanbay M Range
  • Model designation: MCJ-000XX-3-SS-SS4 (product code)
  • Valve designation: SS-SS4, Swagelok metering valve
  • Valve material: Stainless Steel
  • Connection: 1/4 in. compression
  • Line size: 0.25
  • Flow coefficient (Cv): 0.004
  • Maximum pressure rating: 2000 PSI
  • Enclosure options: Aluminum, Stainless-Steel, CSA/IECEx certified Class I Div I (Groups B,C,D)
  • IP rating: IP68 enclosures available
  • Control interfaces: Analog (4-20 mA or 1-5 V), Modbus (RS485), TTL input
  • Feedback: Optional 4-20 mA feedback or none
  • Power: 110-240 VAC; supports battery backup (min. 24 VDC)
  • Auxiliary: Isolated input; prewired Turck M12 connector with 20 ft (approx. 6.1 m) cable
