Electric valve actuator MCJ-000XX-3-SS-8BG-V47

motorizedmanualbattery-powered

Description
Industrial actuated bellows valve assembly designed for pipeline isolation and modulating flow in process systems. Product designation Hanbay M Range. Valve element: bellows-type by Swagelok for leak-tight performance in corrosive and high-purity environments. Assembly configured for 1/2 in. butt-weld connections with a Cv of 1.2 and maximum working pressure 1000 PSI.

Enclosures

• Standard aluminium enclosure
• Stainless-steel enclosure
• Class I Div I Groups B, C, D (CSA and IECEx rated)
• Stainless-steel Class I Div I Groups B, C, D (CSA and IECEx rated)
• IP68 enclosures available

Control Settings

• Analog control: 4-20 mA or 1-5 V
• Modbus (RS485)
• TTL input 0 V (pull to ground) for variable positioning

Feedback Options

• None
• 4-20 mA position feedback

Other Features

• Manual override for local operation
• Power supply: 110-240 VAC
• Battery backup supported (minimum 24 VDC required)
• Isolated input
• Prewired Turck M12 connector with 20 ft (6.1 m) cable

Technical specifications

• Model / Range: Hanbay M Range (product designation)
• Product code: MCJ-000XX-3-SS-8BG-V47
• Valve manufacturer: Swagelok
• Valve type: Bellows valve
• Valve material: Stainless Steel 316
• Valve connection: 1/2 in. butt-weld
• Line size: 0.5 in.
• Flow coefficient (Cv): 1.2
• Maximum pressure rating: 1000 PSI
• Power supply: 110-240 VAC
• Battery backup supported (min. 24 VDC)
• Enclosure options: standard aluminium, stainless-steel, hazardous area (Class I Div I Groups B, C, D) versions, IP68 option
• Control interfaces: Analog 4-20 mA or 1-5 V, Modbus (RS485), TTL input
• Feedback: optional 4-20 mA feedback or none
• Manual override available
• Prewired connector: Turck M12 with 20 ft (6.1 m) cable
