Motorized ball valve actuator MCH-000XX-3-1933TT-SE-200-BAV30
electric90°quarter-turn

Motorized ball valve actuator - MCH-000XX-3-1933TT-SE-200-BAV30 - Rotork - electric / 90° / quarter-turn
Motorized ball valve actuator - MCH-000XX-3-1933TT-SE-200-BAV30 - Rotork - electric / 90° / quarter-turn
Add to favorites
Compare this product
Go to the Rotork website for more information

Characteristics

Type
motorized, electric
Movement
90°, quarter-turn, rotary
Protection class
IP68
Other characteristics
analog, bus-capable, aluminum, stainless steel, single-phase, for ball valves, digital, with backup battery
Voltage

Min.: 110 V

Max.: 240 V

Pressure

Min.: 0 bar
(0 psi)

Max.: 137.9 bar
(2,000 psi)

Rotation angle

Min.: 90 °

Max.: 90 °

Description

Product overview
Compact motorized valve actuator assembly compatible with AVCO 1933TT-SE-200-BAV30 ball valve. Designed for industrial flow control with multiple control and enclosure options.

Valve and performance
  • Valve model: 1933TT-SE-200-BAV30 (AVCO)
  • Valve type: Ball valve
  • Material: Stainless Steel 316
  • Connection: 2 in. FNPT
  • Line size: 2
  • Flow coefficient (Cv): 30.43
  • Maximum pressure: 2000 PSI


Enclosures*
  • Standard aluminum enclosure
  • Stainless-steel enclosure
  • Class I Div I Groups B, C, D (CSA and IECEx rated)
  • Stainless-steel Class I Div I Groups B, C, D (CSA and IECEx rated)
  • IP68 enclosures available*


Control settings
  • Analog: 4-20 mA or 1-5 V
  • Modbus: RS485
  • TTL input: 0 V (pull to ground) for variable positioning


Feedback options
  • None
  • 4-20 mA feedback


Other features
  • Power: 110-240 VAC
  • Battery backup supported (min. 24 VDC required)
  • Isolated input
  • Prewired Turck M12 connector with 20 ft cable


Technical specifications
  • Model / Reference: MCH-000XX-3-1933TT-SE-200-BAV30
  • Series: Hanbay M Range
  • Valve: 1933TT-SE-200-BAV30 (AVCO)
  • Manufacturer: AVCO
  • Valve type: Ball valve
  • Valve material: Stainless Steel 316
  • Connection: 2 in. FNPT
  • Line size: 2
  • Flow coefficient (Cv): 30.43
  • Maximum pressure: 2000 PSI
  • Power: 110-240 VAC
  • Backup power: Battery backup supported (min. 24 VDC)
  • Control interfaces: Analog 4-20 mA or 1-5 V, Modbus RS485, TTL input
  • Feedback: Optional 4-20 mA or none
  • Connector: Prewired Turck M12 with 20 ft cable
  • Available enclosures: Aluminum, Stainless-Steel, CSA/IECEx Class I Div I options, IP68 available
