Data acquisition and analysis software package DAT 3810

monitoringdata collectionfor remote access

Product description
The DAT 3810 software provides data acquisition and remote control for test equipment from SPS electronic. It centralizes test control, execution and evaluation for single devices and custom test systems, with support for common remote interfaces and multilingual operation.

Main features

• Compatible with all SPS electronic device types with an interface
• Operating system: Windows (latest version)
• Barcode filter fields: Article number, Device, Serial number, Comment
• Remote control via: Ethernet, USB, RS-232
• Supported languages: German, English, Chinese, French, Dutch, Italian, Polish, Russian, Spanish, Czech, Turkish, Hungarian

Overview of Functions
1. Create – Intuitive Test Program Creation

• Create complex test sequences easily using mouse and keyboard
• Free design of test flow within programs
• Clear representation of programmed test methods (e.g., continuity test, protective conductor test, high voltage test)
• Unlimited program storage on local disk or network: XML, ACCESS database, SQL database
• Password protection

2. Parameterization – Flexible Adjustment of Test Methods

• Complete and simple parameterization of individual test methods (e.g., for high voltage test: test time, ramp time, test voltage, trip current)
• Program branching to control subsequent test flow depending on step results
• Text and image display steps to guide the operator or request additional input

3. Testing – Efficient Execution of Tests

• The TEST module displays the current sequence of the selected test program
• During each test step results and progress are shown
• Manual single-step mode for troubleshooting complex tests
• Large PASS / FAIL display

4. Results – Comprehensive Evaluation & Documentation

• Test results and measured values are saved in XML, ACCESS or SQL formats for traceability and further processing
• Statistics function with extensive selection criteria
• Full-text search
• Test reports printable or savable as PDF

Technical specifications

• Model: DAT 3810
• Brand: SPS electronic
• Suitable for: all SPS electronic device types with an interface
• Operating system: Windows (latest version)
• Supported remote-control interfaces: Ethernet, USB, RS-232
• Barcode filter fields: Article number, Device, Serial number, Comment
• Program/result storage formats: XML, ACCESS database, SQL database
• Key features: intuitive editor for complex test sequences, password protection, program branching, text/image guidance, manual single-step mode
• Results & reports: saved in XML/ACCESS/SQL, statistics, full-text search, printable and PDF reports
• Net price (page): 1272 EUR
