TFT LCD display module LMT150DNGFWD-NNC-4projected capacitive touchscreencolor1024 x 768
Add to favorites
Compare this product
Characteristics
- Screen type
- TFT LCD, projected capacitive touchscreen
- Type
- color
- Format
- 1024 x 768
- Screen size
- 15"
- Applications
- industrial
- Interface
- LVDS
- Width
342 mm
(13.4646 in)- Height
266 mm
(10.4724 in)- Depth
23 mm
(0.91 in)- Operating temperature
Min.: -20 °C
(-4 °F)Max.: 70 °C
(158 °F)
Description
Product
15.0" color TFT LCD module LMT150DNGFWD-NNC-4 with LVDS interface and projected capacitive touch (CTP). Suitable for industrial display applications requiring 1024x768 resolution and 400 cd/m² luminance.
Key information
Other features
Technical specifications
15.0" color TFT LCD module LMT150DNGFWD-NNC-4 with LVDS interface and projected capacitive touch (CTP). Suitable for industrial display applications requiring 1024x768 resolution and 400 cd/m² luminance.
Key information
- Resolution: 1024 x 768
- Interface: LVDS
- Operating voltage: 3.3 V
- Operating temperature: -20°C to 70°C
- Wide viewing angle: No
- Outline dimensions: 342.0 x 266.0 x 23.0 mm
- Display size: 15.0"
- Active area (A. A.): 304.13 x 228.10 mm
- Touch screen: CTP (Projected Capacitive)
Other features
- Brightness: 400 cd/m²
Technical specifications
- Model: LMT150DNGFWD-NNC-4
- Panel type: Color TFT LCD module
- Resolution: 1024 x 768 pixels
- Interface type: LVDS
- Touch type: Projected capacitive (CTP)
- Operating voltage: 3.3 V
- Operating temperature range: -20°C to 70°C
- Outline (W x H x D): 342.0 x 266.0 x 23.0 mm
- Active area (A. A.): 304.13 x 228.10 mm
- Luminance / Brightness: 400 cd/m²
- Wide viewing angle: No
