DC electronic load EA-EL 9500-08 DT 400Wprogrammable
Add to favorites
Compare this product
Characteristics
- Options
- DC, programmable
- Power
400 W
- Voltage
Min.: 0 V
Max.: 500 V
- Current
Min.: 0 A
Max.: 8 A
Description
Overview
The EA-EL 9500-08 DT is a programmable desktop/3U rack DC power supply delivering up to 400 W with an output range of 0–500 V and 0–8 A. It features U/I/P autoranging, an integrated function generator and resistance mode, and a touch-panel user interface for local operation.
Main information
Additional features
Technical specifications
The EA-EL 9500-08 DT is a programmable desktop/3U rack DC power supply delivering up to 400 W with an output range of 0–500 V and 0–8 A. It features U/I/P autoranging, an integrated function generator and resistance mode, and a touch-panel user interface for local operation.
Main information
- Compact 3U / 19" rack housing suitable for bench or rack-mounted use.
- Touch panel and menu-driven human interface for local control and configuration.
- Remote/external control via Analogue (0–5 V / 0–10 V), USB, LAN and Modbus.
Additional features
- Characteristic curve: U/I/P autoranging (automatic switching between voltage, current and power modes) for flexible testing.
- Special functions: Built-in function generator and resistance mode for advanced testing and simulation.
Technical specifications
- Article Number: HEA7021
- Manufacturer Code: 33210504
- Manufacturer: EA
- Output Voltage: 0-500 V
- Output Current: 0-8 A
- Output Power: 400 W
- Type: 3U
- Characteristic Curve: U/I/P autoranging
- External Control: Analogue 0-5V / 0-10V, USB, LAN, Modbus
- Housing: 19" rack
- Human Interface: Touch panel & Menu
- Special Feature: Function Generator, Resistance mode
