DC electronic load EA-ELR 10200-25 2U

energy recoveryprogrammableLAN

Overview

The EA-ELR 10200-25 2U is a programmable electronic DC load from the EA-ELR 10000 2U series designed for laboratory and industrial test applications. It offers energy-recovery capability, a compact 2U 19-inch rack form factor and a wide set of control and protection functions for precise, repeatable DC testing.

Key features

• Programmable DC electronic load with energy recovery up to 94.5%.
• Rated output up to 1500 W (derates to 1200 W at 110-127 V AC); output voltage 0-200 V; output current 0-25 A.
• Multiple operating modes: CV, CC, CP, CR and additional resistance mode and built-in function generator.
• Intuitive local interface: 5-inch color TFT touchscreen and rotary knobs with decimal switching; DC on/off control and clear status display.
• Extensive remote and analog interfaces: galvanically isolated USB, Ethernet (SCPI / ModBus RTU), 15-pin D-Sub analog I/O (0-5 V / 0-10 V); compatible with LabView VIs and EA Power Control software.
• Scalable operation: parallel operation support (up to 64 units) and remote sensing for higher power or distributed testing.
• Comprehensive protections and front-to-rear, temperature-controlled cooling for reliable operation in lab and industrial environments.

Technical specifications

• Article Number (internal): HEA3689
• Manufacturer / Brand: EA (EA Elektro-Automatik), Ordering Number: 33200841
• Output Power: 1500 W (derates to 1200 W at 110-127 V AC)
• Output Voltage Range: 0-200 V
• Output Current Range: 0-25 A
• Characteristic Curve: U / I / P autoranging
• Type / Height: 2U (19-inch rack)
• Housing / Mounting: 19-inch rack enclosure; enclosure dimensions: 19" x 2U x 462 mm, total depth min. 559 mm
• Human Interface: 5-inch color TFT touchscreen (800 x 480, Gorilla Glass) plus two rotary knobs and DC on/off button
• External Control / Interfaces: galvanically isolated USB; Ethernet (SCPI / ModBus RTU); 15-pin D-Sub analog interface (0-5 V / 0-10 V); LabView compatibility; EA Power Control software
• Parallel Operation: up to 64 units supported; remote sensing supported
• Efficiency / Energy Recovery: up to 94.5% energy recovery (feeds DC energy back to the grid)
• AC Input: 100-264 V AC with active PFC (PF ≈ 0.99); leakage current < 3.5 mA; inrush approx. 23 A @ 230 V
• Regulation / Speed: CV regulation ≤ 0.05% FS; CC regulation ≤ 0.1% FS; CC rise/fall time ≤ 10 ms
• Insulation: 3750 Vrms (AC-DC), ±1000 V DC (DC-PE)
• Cooling: temperature-controlled fans, front-to-rear airflow
• Protections: OVP, OCP, OPP, OT, PF (shutdown of DC input on anomalies)
• Operating Conditions: 0-50 °C, ≤ 80% non-condensing humidity, altitude ≤ 2000 m
• Storage Conditions: -20 to 70 °C
• Dimensions & Weight: enclosure 19" x 2U x 462 mm; total depth min. 559 mm; weight ~9.5 kg
• Standards / Compliance: EN 61010-1; EN 55011 Class B
• Special Features: built-in function generator, resistance mode; suitable for industrial testing, prototype validation and laboratory use
