Tabletop power supply EA-PSI 9040-40 DT

AC/DCDCCE

Overview

The EA-PSI 9040-40 DT is a programmable desktop DC power supply delivering 0–40 V and 0–40 A. Available in 640 W and 1000 W power classes, it features an auto-ranging output stage, low-noise filtering and multiple standard interfaces for laboratory, test bench and industrial integration.

Key features

• Auto-ranging 0–40 V / 0–40 A: Flexible U/I/P autoranging maximizes usable power across voltage/current combinations.
• Two power variants: 640 W (standard) and 1000 W (high-power) options for high-current applications.
• High efficiency & universal input: Up to 92% efficiency; 90–264 V AC input with active PFC (>0.99).
• Intuitive user interface: Color TFT touchscreen, two rotary knobs and multilingual menu (German, English, Russian, Chinese).
• Standard remote interfaces: USB (control and data), LAN (Ethernet), galvanically isolated analogue interface; supports SCPI and Modbus TCP.
• Integrated function generator & resistance simulation: Built-in true function generator and internal resistance regulation for dynamic testing.
• Protections & low noise: Configurable OVP, OCP, OPP, OT and low ripple (640 W: 8 mVpp / 0.8 mVrms; 1000 W: 10 mVpp / 1.5 mVrms).

Technical specifications

• Output voltage: 0–40 V
• Output current: 0–40 A
• Output power: 640 W (standard) / 1000 W (high-power)
• Characteristic curve: U/I/P auto-ranging
• External control: Analogue 0–5 V / 0–10 V, USB, LAN, Modbus TCP
• Housing: Desktop (table)
• User interface: Touch panel, two rotary knobs
• AC input range: 90–264 V AC with active PFC (>0.99)
• Efficiency: Up to 92%
• Protections: Configurable OVP, OCP, OPP, OT
