DC electronic load EA-EL 9360-20 DT 900Wprogrammable
Add to favorites
Compare this product
Characteristics
- Options
- DC, programmable
- Power
900 W
- Voltage
Min.: 0 V
Max.: 360 V
- Current
Min.: 0 A
Max.: 20 A
Description
The EA-EL 9360-20 DT is a programmable DC power supply delivering up to 900 W suitable for both high-voltage/low-current and low-voltage/high-current applications. It is available as a desktop unit or in a 3U 19" rack housing.
Key product information
Control & interfaces
Design & functions
Technical specifications
Key product information
- Output voltage range: 0–360 V
- Output current range: 0–20 A
- Rated output power: 900 W
Control & interfaces
- External control: Analogue 0–5 V / 0–10 V, USB, LAN, Modbus
- Local operation: Touch panel with menu navigation
Design & functions
- Form factor / housing: 3U, 19" rack or desktop
- Characteristic curve: U/I/P autoranging (automatic switching between voltage/current/power)
- Special functions: Built-in function generator, resistance mode
Technical specifications
- Output Voltage: 0–360 V
- Output Current: 0–20 A
- Output Power: 900 W
- Type: 3U / 19" rack or desktop
- Characteristic Curve: U/I/P autoranging
- External Control: Analogue 0–5 V / 0–10 V, USB, LAN, Modbus
- Housing: 19" rack or desktop
- Human Interface: Touch panel & menu
- Special Feature: Function generator, resistance mode
