Laboratory moisture balance SCIROCCO & LIBECCIO | 172B - 245B

electronicgdigital

Product overview
Automatic moisture regain oven designed to measure moisture regain and humidity content percentage in textile materials according to ISO, ASTM, IWTO, UNI and UNI EN ISO standards.

Key features

• Software and PC operated
• Quick sample drying (in about 10 min) by suction cycle
• Adjustable drying temperature up to +140°C

Testing procedure details

• The cabinet automatically continues weighing until the sample attains a stable dry mass
• The computer evaluates the difference among consecutive weighings and the test stops when the difference between two consecutive weighings is lower than 0,05%
• It is possible to determine the duration of the first drying cycle as well as the duration of the further 9 cycles
• The basket tare is recorded according to the basket code
• Ambient humidity and temperature values can be entered in order to obtain automatically the correction of the dry mass (the software includes a table of correction coefficients)

Equipment supplied / options

• PC
• Electronic balance: 2200 g capacity / 0,01 g accuracy
• Colour printer
• LCD monitor

Printed report (test parameters and final results)

• Sample code
• Basket code
• Date of basket gauging
• Weight of wet sample
• Weight of dry sample
• Dry percentage

Temperature monitoring
A graph for temperature monitoring can be displayed during the test.

Versions

• Scirocco — fully automatic (Code 172B)
• Libeccio — semi-automatic (Code 245B), without PC and software; activation of heating and weighing steps requires manual attendance

Reference standards

• UNI EN ISO 2060, ISO 2060, ISO 6348, ISO 6741-1, ISO 6741-2, ISO 6741-3, ASTM D1576, ASTM D2495, IWTO 33 - 03, IWTO 34 - 98, UNI 1335, UNI 9213-1, UNI 9213-2, UNI 9213-3, UNI 9213-4, UNI 9213-5, UNI 9213-6

Caractéristiques / spécifications techniques

• Electronic balance capacity: 2200 g; readability/accuracy: 0,01 g
• Adjustable drying temperature: up to +140°C
• Typical quick drying time: approx. 10 minutes (suction cycle)
• Automatic weighing until stable dry mass; stop criterion: difference between consecutive weighings < 0,05%
• Configurable cycle durations: first drying cycle plus further 9 cycles
• Basket tare recorded by basket code
• Ambient humidity and temperature correction via software (correction coefficient table available)
• Printed report includes sample/basket codes, dates, wet and dry weights, dry percentage; temperature graph display available
• Available versions: Scirocco (fully automatic) and Libeccio (semi-automatic)
