Cabinet oven 251G

dryingcleaningforced convection

Overview
High-tech oven designed for conditioning and testing in textile laboratories: suitable for crimp checking in yarns and for verifying dimensional stability of fabrics exposed to hot air. Also used for hot cleaning of mechanical spinnerets, drying and heating of various textiles.

Main features

• Suitable for hot cleaning of mechanical spinnerets, drying and heating of textiles
• Supplied with digital temperature regulator and two stainless-steel grid shelves
• Forced ventilation ensures uniform heat circulation
• Operating temperature range: +50°C to +280°C
• Temperature accuracy: ±1°C

Versions

• Forced Ventilation Conditioning Oven (Code 251G)
  • Inside dimensions (L x W x H): 408 x 372 x 422 mm
  • Capacity: 60 l
  • Weight: 44 kg
• Forced Ventilation Conditioning Oven (Code 251H)
  • Inside dimensions (L x W x H): 498 x 477 x 512 mm
  • Capacity: 120 l
  • Weight: 60 kg
• Forced Ventilation Conditioning Oven (Code 251P)
  • Inside dimensions (L x W x H): 593 x 522 x 797 mm
  • Capacity: 250 l
  • Weight: 90 kg

Technical specifications

• Product type: Forced-ventilation conditioning oven for laboratory and textile applications
• Temperature range: +50°C to +280°C
• Temperature accuracy: ±1°C
• Heat circulation: Forced ventilation
• Control: Digital temperature regulator (supplied)
• Shelves: Two stainless-steel grid shelves (supplied)
• Suitable uses: Crimp checking in yarns; dimensional stability testing of fabrics exposed to hot air; hot cleaning of mechanical spinnerets; drying and heating of textiles
• Variant 251G: inside dims 408 x 372 x 422 mm; capacity 60 l; weight 44 kg
• Variant 251H: inside dims 498 x 477 x 512 mm; capacity 120 l; weight 60 kg
• Variant 251P: inside dims 593 x 522 x 797 mm; capacity 250 l; weight 90 kg
