Digital ohmmeter 291B

bench-top

Product overview
Equipment designed to assess static electricity properties of textiles, protective fabrics, footwear materials and leather using surface and vertical resistance measurement methods.

Composition

• Electronic control panel for digital reading of static resistance (Ohm)
• Connecting cables
• Probes for surface and vertical static measurements

Reference standards

• UNI EN 1149-1
• UNI EN 1149-2
• AATCC 76
• DIN 54345-1

Note
Before measurement, condition samples at +23°C ±1° and relative humidity 25% ±5% using Climatest (Code 1722).

CLIMATEST
Climatest is a laboratory instrument for conditioning textiles (fibers, yarns, fabrics and garments) at constant temperature and humidity according to ISO/ASTM standards.

Accessories

• Static Lab calibration box (Code 291B.2) — optional

Technical specifications

• Model: Static Lab 291B
• Measurement units: electrical resistance (Ohm) — digital reading
• Measurement methods: surface and vertical static resistance (probes included)
• Included components: electronic control panel, connecting cables, probes
• Reference standards: UNI EN 1149-1; UNI EN 1149-2; AATCC 76; DIN 54345-1
• Sample conditioning required: +23°C ±1°, R.H. 25% ±5% (use Climatest, Code 1722)
• Optional accessory: Static Lab calibration box (Code 291B.2)
