Rotative dyeing machine 323S5

textilefor fabricssemi-automatic

Product overview
Laboratory instrument for atmospheric dyeing (max +98°C), suitable for dyeing and washing of tubular fabrics, knitted cloths and other orthogonal fabrics (samples of carpets and fitted carpets are included).

Main features

• Dimensions of rotating drum: Ø 450 x 500 mm
• Dyeing bath capacity: 60 liters
• Programmable microprocessor: up to 50 programs can be saved
• Sample load: depending on the type of sample, possible to dye or wash about 2.5 kg of fabrics
• Temperature control and regulation of dyeing bath: maximum +98°C

Optional
Automatic loading of dyeing recipe, dosing of auxiliary products and final bath drain.

Available on request (other dyeing capacities)

• 20 liters (Code 323D)
• 38 liters (Code 323S2)
• 240 liters (Code 323S7)

Technical specifications

• Product type: Laboratory instrument for atmospheric dyeing
• Max dyeing temperature: +98°C
• Rotating drum dimensions: Ø 450 x 500 mm
• Dyeing bath standard capacity: 60 liters
• Programmable microprocessor: up to 50 saved programs
• Approximate fabric load per batch: about 2.5 kg (depending on sample type)
• Optional functions: automatic loading of dyeing recipe, dosing of auxiliary products, final bath drain
• Alternative models available with different bath capacities: 20 L (323D), 38 L (323S2), 240 L (323S7)
