Differential pressure decay leak tester F6900-EC

vacuumfor the pharmaceutical industryfor ampoules

Description
The F6900 EC is a benchtop vacuum decay leak tester designed for non-destructive integrity testing of primary packaging. It is suitable for laboratory testing, statistical sampling and off-line quality control. The instrument implements ATEQ vacuum decay technology and features an intuitive HMI for easy cycle setup. Measurement follows ASTM F2338-09 (recognized by U.S. FDA CDRH).

Applications

• Pharmaceutical packaging
• Liquid dosage forms
• Ampoules
• Blow–Fill–Seal (BFS) containers
• Bottles and vials
• Carpules (cartridges)

Features

• Online or offline operation modes
• ASTM F2338-09 compatible measurement method
• Stainless steel construction for GMP environments
• High test sensitivity (< 1 µm)
• Differential vacuum decay measurement
• Non-invasive, non-destructive test method
• Cost-effective solution for batch control
• Graphic HMI with real-time test cycle display

Options

• Leak flow calibrator
• Custom test chamber
• Specialized connectors and adaptors

Specifications

• Weight: 24 Kg
• Dimensions (WxHxD): 450 x 550 x 356 mm
• Graphic color HMI with intuitive menu
• Electrical supply: 100–240 V AC, 50 W
• Test pressure: Absolute 1 Torr
• Air: clean, dry, compliant with ISO 8573-1
• Operating temperature: 0°C to +45°C
• Storage temperature: 0°C to +60°C
• Test sensitivity: < 1 µm
• Method: Differential vacuum decay (ASTM F2338-09)
