Climate chamber CIT10-10S

humiditytemperaturepressure

Product description
The CIT10-10S enclosed-space aerosol ignition tester evaluates aerosol flammability in a closed or restricted volume in accordance with UN 'Recommendations on the Transport of Dangerous Goods — Manual of Tests and Criteria' (section 31.5) and GB/T 21631-2008. The instrument reproduces confined-space conditions to determine whether ignition, flash or explosion occurs when an aerosol is discharged.

Instrument overview
The system comprises a display/control unit and a detection module. The detection module is a cylindrical vessel with integrated optical sensors and a high-precision thermocouple to detect ignition or knocking events. The display/control unit features an LCD for real-time monitoring and test control. Aerosol cans are positioned and actuated automatically; the device supports vertical and inverted orientations.

Product parameters

• Operating environment: 5 ℃ to 30 ℃, <85% RH
• Ambient temperature measurement range: -10 ℃ to +60 ℃; accuracy ±0.5 ℃
• Humidity range: 5% to 95% RH; accuracy ±3.0% RH
• Combustion detection response time: ≤6 ms
• Differential pressure measurement range: -5 to 5 kPa; accuracy ±0.1% FS
• Timing accuracy: ±0.1 s
• Ignition source: standard candle flame, adjustable pedestal height 20 mm
• Cylindrical vessel dimensions: Φ600 mm × 720 mm
• Aerosol can handling: automatic flip for orientation
• Compatible aerosol can size: height 120–400 mm, diameter 30–70 mm
• Nozzle-to-vessel distance: adjustable 30–35 mm
• Effusion plate: removable collector for discharged liquid

Product features

• Embedded processor with Windows CE
• 8-inch LCD touch screen for real-time status and control
• Two operation modes: Standard and Custom
• Automatic spray actuation and clamping; supports upright and inverted cans
• Dual detection: differential pressure sensors and nanosecond light sensors to capture flame or explosion events
• Integrated ventilation to exhaust smoke from the vessel for test accuracy and operator safety
• Fully automated test sequence with parameter setting, data storage and report viewing
• Temperature and humidity module for real-time environment monitoring

Technical specifications

• Model: CIT10-10S
• Cylindrical vessel: Φ600 mm × 720 mm
• Working environment: 5 ℃ to 30 ℃, <85% RH
• Ambient temperature range: -10 ℃ to +60 ℃; accuracy ±0.5 ℃
• Humidity range: 5% to 95% RH; accuracy ±3.0% RH
• Pressure (differential) range: -5 to 5 kPa; accuracy ±0.1% FS
• Combustion detection response time: ≤6 ms
• Timing accuracy: ±0.1 s
• Compatible aerosol can size: height 120–400 mm, diameter 30–70 mm
• Nozzle distance adjustable: 30–35 mm
• User interface: 8-inch LCD touch screen running Windows CE
