Thermostatic test chamber CIT20-10S

humiditytemperatureheating

Short description
CIT20-10S Koenen test instrument for determining thermal sensitivity of solid and liquid substances under high confinement heating conditions. Compliant with UN Recommendations on the Transport of Dangerous Goods — Section 11.5.1 Test 1(b).

Product description
The CIT20-10S is designed to evaluate the thermal sensitivity of materials by heating a sample contained in a steel pipe against a standard steel plate. The system performs automatic electronic ignition, controlled heating and precision timing; heating stops automatically at the end of the programmed sequence. After each run an automatic report is generated for review and interpretation of steel deformation or rupture to determine material sensitivity.

Product features

• Embedded processor running Windows CE
• 8-inch LCD touch screen showing test status in real time
• Two operation modes: Standard model and Calibration Mode
• Automatic electronic ignition with remote-control option
• Automatic specimen preparation with 80 N constant pressure for reproducible sample compaction
• Heating-rate control via flow meter for precise thermal ramp
• Integrated automatic heating and timing sequence
• Front door openable for direct inspection and quick cleaning
• Integrated video monitoring system for recording and playback; supports remote observation
• Full automation for parameter setting, data storage and report viewing

Product parameters

• Operating environment: 5 ℃ ~ 30 ℃, <85% RH
• Temperature measuring range: 0 ~ 500 ℃
• Temperature measurement accuracy: below 300 ℃ ±2.5 ℃; above 300 ℃ ±(0.75% of reading)
• Sample preparation pressure: 80 N
• Sample preparation ballast weights accuracy class: F2
• Heating rate: 3.3 ± 0.3 K/s
• Steel weight: 26.5 g ± 1.5 g
• Pipe wall thickness: 0.5 mm ± 0.05 mm
• Orifice apertures available: 1.0 mm, 1.5 mm, 2.0 mm, 2.5 mm, 3.0 mm, 5.0 mm, 8.0 mm, 12.0 mm, 20.0 mm
• Pipe size Φ (outer diameter) × H: 25 mm × 75 mm

Technical specifications

• Compliance: United Nations “Recommendations on the Transport of Dangerous Goods” — Section 11.5.1 Test 1(b) (Koenen test)
• Control: Embedded processor (Windows CE)
• Display: 8-inch LCD touch screen for real-time status and interaction
• Modes: Standard model and Calibration Mode to match test protocols
• Ignition: Automatic electronic ignition with remote-control capability
• Specimen preparation: 80 N constant pressure automatic system; ballast weights class F2
• Heating control: Auto-heating with timing and flow-meter-based heating-rate control
• Automation: Fully automated test sequence with parameter setting, data logging and automatic report generation
• Monitoring: Integrated video system for process recording, playback and remote review
• Mechanical: Standard steel plate at one end; steel weight 26.5 g ±1.5 g; pipe wall 0.5 mm ±0.05 mm; selectable orifice apertures as listed; pipe Φ25 mm × H75 mm
• Environmental range: 5 ℃ to 30 ℃, humidity <85% RH
• Temperature range & accuracy: 0–500 ℃; accuracy below 300 ℃ ±2.5 ℃; above 300 ℃ ±0.75% of reading
• Heating rate specification: 3.3 ± 0.3 K/s
