Semi-automatic filling and sealing machine TGM E250

for tubesliquidsfor pasty products

Overview
High-speed semi-automatic tube filling and sealing machine designed for pharmaceutical, cosmetic and food production. Semi-automatic operation (tubes loaded by hand) with precision alignment and pharma-grade hygienic design. Typical throughput: up to 2,500 metal tubes/hour or 2,000 laminate/polyethylene tubes/hour.

Product details

• Hand-loaded tubes: Up to 2,500 metal tubes/hour or 2,000 laminate/polyethylene tubes/hour.
• Advanced sealing technology: Metal tubes – fold and roll crimping; Plastic/laminate tubes – hot-air or hot-jaw sealing for clean, professional finishes.
• Self-aligning tube orientation system: Sensor verifies print position to ensure correct alignment and reduce rejects.
• Hygienic, pharma-grade construction: Crevice-free surfaces and lubricant-free mechanics to minimise contamination risk and facilitate cleaning.
• Consistent and accurate filling: Controlled dosing reduces product waste and supports batch quality.
• Automated tube ejection: Streamlined cycle to maximise operator efficiency.
• Flexible tube sizes: Accepts a wide range of diameters and lengths to accommodate diverse product portfolios.

Applications

• Pharmaceutical creams and gels
• Cosmetic products (balms, serums, lotions, pastes)
• Food pastes and nutraceuticals
• Veterinary and personal-care formulations

Materials supported

• Metal tubes
• Polyethylene (PE) tubes
• Laminated tubes

Sealing technologies

• Metal tubes: fold and roll crimping
• Plastic/laminate tubes: hot-air sealing or hot-jaw sealing

Options and upgrades

• Heated hopper
• Agitator/scraper for thick or settling products
• Product level control
• Advanced tube orientation system
• Water chiller

Technical specifications

• Model: TGM E250Semi
• Speed: Up to 2,500 metal tubes/hour, 2,000 laminate/PE tubes/hour
• Typical power consumption (metal): 1.5 kW
• Typical power consumption (plastic): 5 kW
• Water consumption: 1-2 l/min
• Air (metal): 150 l/min
• Air (plastic): 300 l/min
• Metal tube diameters: 10 - 42 mm
• Plastic tube diameters: 10 - 50 mm
• Tube length: 50 - 240 mm
