Multitouch screen panel PC W07IE3S-EHO1

PCAP capacitive touch screen1000 nits7"

Overview
Winmate W07IE3S-EHO1 is a 7-inch E Series HMI Panel PC powered by Intel® Celeron® N6211, designed for machine control, factory automation and operator HMI. It delivers a compact, fanless, low-power industrial computing platform with long-lifecycle availability, front IP65 protection and multiple connectivity options for OEMs and system integrators.

Key features

• 7" 1024 x 600 P-CAP multi-touch display
• Intel® Celeron® N6211 processor (up to 3.0 GHz)
• Front IP65 water and dust protection
• Dual 2.5 Giga LAN Ethernet (Intel® controllers)
• Fanless design and ultra-low power consumption; optional PoE

Design highlights

• True flat front panel with scratch-resistant glass
• PoE support to combine data and power wiring
• Panel mounting clips for quick installation; optional VESA mount
• P-Cap touch supporting multi-touch interaction

Certifications & protection

• Front IP65
• CE and FCC certified

Technical specifications

• Model: W07IE3S-EHO1
• Display: 7.0 inches, 1024 x 600, 1000 nits, 700:1
• Active area: 153.6 x 90 mm
• Processor: Intel® Celeron® N6211 (up to 3.0 GHz)
• Memory: 4GB default; 8GB, 16GB optional
• Storage: 128GB SSD default; up to 2TB optional
• Ethernet: 2 x 2.5 Giga LAN RJ45
• Security: TPM 2.0
• I/O: 2 x USB3.2 Gen2 Type-A; 1 x RS232/422/485; 1 x HDMI 2.0 (optional); M.2 2230 E-Key
• Power: 12V DC input, adapter 12V 50W
• Dimensions: 185 x 128 x 56 mm; Cut out: 174.9 x 117.7 mm; Weight: 0.9 kg
• Operating: 0°C to 50°C; Humidity 10%–90% RH non-condensing
