LED floodlight JNHM2-450S-5000-A5-DIM

HIDHPSIP65

Product overview
This JNHM2-450S-5000-A5-DIM LED high-mast floodlight delivers 450 W (system 495 W) with Philips Lumileds LEDs and Meanwell HLG-480H driver. Fixed symmetric 90°×90° beam, 5000 K (cool white), total output 51,500 lm and efficacy 120 lm/W. Dimmable via 0-10V control. IP65 and IK08-rated for outdoor industrial installations; designed to replace 1000 W metal halide HID/HPS equivalents.

Key features

• Original Philips Lumileds LEDs
• Meanwell HLG-480H LED driver
• Dimmable control: 0-10V
• Fixed symmetric beam: 90°×90°
• Ingress protection: IP65; impact rating: IK08
• Surge protection up to 10 kV
• Colour temperature: 5000 K, CRI >70
• Housing colour: Marine-Grey; lens: tempered glass

Technical specifications

• SKU: JNHM2-450S-5000-A5-DIM
• Power consumption: 450 W (system power: 495 W)
• Input voltage: 120–277 V AC (347–488 V AC optional)
• Total luminous flux: 51,500 lm; efficacy: 120 lm/W
• Beam angle: 90°×90° (fixed, symmetric)
• LED type: Philips Lumileds; number of LED modules: 4
• Driver brand: Meanwell HLG-480H; dimming: 0-10V
• Surge protection: 10 kV; power factor >0.95
• Colour rendering index (CRI): >70; colour temperature: 5000 K
• Lens material: tempered glass; IK rating: IK08
• Operating temperature: -20°C to 45°C; humidity: 10%–95% RH
• Lifespan: 80,000 hours
• Input cable: H07RN-F 3G1.0
• Fixture dimensions (H×L×W): 550×480×320 mm; net weight: 10 kg
• Warranty: 5 years

Applications

• Port areas and quays
• Stadiums and sports facilities
• Logistics yards and industrial sites
• Airfields and apron lighting
• Large outdoor storage and container terminals

Packaging & Shipping

• Net weight: 10 kg; export carton gross weight: 13 kg
• Export carton dimensions: 900×700×320 mm
• Products per carton: 2

Warranty & compliance

• 5-year warranty
• Meets IP65 and IK08 protection classes
• Surge protection to 10 kV; power factor >0.95
