LED floodlight JNHM1-450S-5000-A4-DIM

HIDHPSIP65

Product description
450 W LED high-mast flood light JNHM1-450S-5000-A4-DIM equipped with Philips Lumileds and Meanwell HLG-480H drivers. Dimmable (0-10V). IP65 and IK08 protection; tempered glass lens. Delivers 63,500 lm (140 lm/W) at 5000 K, suitable for stadiums, ports, yards and industrial sites. Designed to replace high-power metal halide/HID/HPS fixtures.

Product specifications
Product SKU: JNHM1-450S-5000-A4-DIM
Power Consumption: 450 W
System Power: 495 W
Input Voltage: 120-277 V AC (optional 347~488 V AC)
Beam Angle (°): 30°
Beam Angle Range: 30°x140° (Fixed)
IP Rating: IP65
IK Impact Rating: IK08
Color Rendering Index: >70
LED Type: Philips Lumileds
Color Temperature (K): 5000
Dimming Capability: 0-10V
LED Driver Brand: Meanwell HLG-480H
Lens Material: Tempered Glass
Housing Colour: Marine-Grey
Surge Protection: 10 kV
Power Factor: >0.95
Input Cable: H07RN-F 3G1.0
Working Temperature Range: -20°C ~ 45°C
Working Humidity Range: 10%-95% RH
Lifespan (Hours): 80,000 hours
Number of LED Modules: 4 modules
Fixture Dimensions (H×L×W): 854 mm × 610 mm × 238 mm
Total Lumens Output: 63,500 lm
Efficacy (lm/W): 140 lm/W

Technical features

• Power Consumption: 450 W
• Input Voltage: 120-277 V AC (optionally 347~488 V AC)
• Beam Angle: 30° / Beam Angle Range: 30°x140° (Fixed)
• IP Rating: IP65
• CRI: >70
• LED Type: Philips Lumileds
• Colour Temperature: 5000 K
• IK Rating: IK08
• Dimming: 0-10V
• Housing Colour: Marine-Grey
• Warranty: 5 years
• Power Factor: >0.95
• Surge Protection: 10 kV
• Input Cable: H07RN-F 3G1.0
• Operating Temp Range: -20°C ~ 45°C
• Operating Humidity: 10%-95% RH
• Lifespan: 80,000 hours
• Number of LED Modules: 4
• LED Driver Brand: Meanwell HLG-480H
• Lens Material: Tempered Glass
• System Power: 495 W
• Dimensions (H×L×W): 854 mm × 610 mm × 238 mm
• Total Lumens: 63,500 lm
• Efficacy: 140 lm/W
