Filter dust collector DBF20

manual cleaningfor the textile industrycompact

Presentation
Compact three‑phase industrial vacuum designed for direct extraction of dust and chips at source. Intended for OEM integration and continuous 24/7 operation. Horizontal compact design simplifies installation on production lines and in confined workshop spaces.

Main features

• Three‑phase side‑channel blower (400 V) providing continuous suction.
• Motor power: 1.8 kW (1800 W).
• Integrated safety valve protecting the motor from overloads.
• M‑class antistatic polyester pocket filter, effective on fine and hazardous dust.
• Manual filter unclogging by handle for easy cleaning and simplified maintenance.
• Robust 25 L collection vessel suitable for industrial environments.
• Compact horizontal layout, ideal for OEM integration and installation close to machines.

Performance and use

• Nominal airflow: up to 270 m3/h.
• Indicated nominal vacuum: 2200 mmH₂O (operating value).
• Maximum indicated vacuum: 3000 mmH₂O.
• Sound level: 70 dB(A), suitable for use near operators.
• Designed for continuous extraction (24/7) on production machines.

Typical applications

• Direct extraction on machines (OEM).
• Collection of fine and hazardous dust.
• Suitable for textile fibers, industrial dust, chips, etc.

Technical specifications

• Model: DBF20
• Brand: Pharaon
• Power: 1.8 kW (1800 W)
• Voltage: 400 V (three‑phase)
• Blower: three‑phase side‑channel
• Max airflow: 270 m3/h
• Indicated vacuum: 2200 mmH₂O
• Max vacuum: 3000 mmH₂O
• Sound level: 70 dB(A)
• Collection vessel: 25 L
• Dimensions: 84 x 44 x 67 cm
• Weight: 40 kg
• Primary filter: ANT M
• Filtration: M‑class antistatic polyester pocket filter (indicated area: 8,000 cm², Ø 360 mm)
• Alternative indicated filter area: 2000 cm²
• Unclogging: manual by handle
• Air inlet: 50 mm
