Polymer electric fusion machine Prisma90

for industrial applications

The Prisma90 is a bench socket fusion machine engineered to weld thermoplastic pipes (HDPE, PPR, PPH, PB, PVDF) with precise, repeatable results. It covers pipe diameters from 20 mm to 90 mm (1″–4″ IPS) and uses mechanical control to standardize the welding operation for consistent joint quality.

Key features

• Precise gauge for weld depth to ensure consistent fusion.
• Accurate fit-depth control for repeatable joints.
• Mechanical operation standardizes the welding process and improves repeatability.

Applications

• Potable water supply systems
• Drainage and sewer systems
• Industrial fluid transport and piping installations

Warranty & certificates
2-year quality warranty; technical support available; CE certificate supplied.

Technical specifications

• Applicable pipe diameter: 20 mm – 90 mm
• Rated voltage: A.C. 220/230 V, 50/60 Hz
• Power: 1200 W
• Working temperature (heater): 200 ~ 279 ℃ ±1%
• Ambient temperature: -5 ℃ ~ 45 ℃
• Applicable materials: PP-R, PE (HDPE), PP, PB, PVDF
• Net weight: 76 kg
• Carton size (packaging): 800 × 600 × 400 mm
