Polymer electric fusion machine THJ-110Efor industrial applicationsresistance
Add to favorites
Compare this product
Characteristics
- Processed material
- polymer
- Application
- for industrial applications
- Furnace type
- resistance
- Maximum temperature
260 °C
(500 °F)
Description
Product overview
Key features
Applications
Fusion instructions (summary)
Technical specifications
- Portable socket fusion welder THJ-110E designed for plumbing and hot/cold water installations on thermoplastic pipes. Supplied with a two-year quality warranty and free spare parts.
Key features
- Square base for enhanced stability during welding.
- High-quality aluminium heating plate (up to 19 mm thickness) with optional Teflon surface.
- Heating element versions: 110 V or 220 V.
- Lightweight and portable (net weight 2.0 kg) with ABS + nylon handle.
- LED work light and digital temperature display for process control.
- VDE copper cable with rubber sheath (up to 3 m) and international plug support.
- Steel housing (1.0 mm) with OEM color/marking options.
Applications
- Plumbing and pipe installation
- Hot water supply systems
- Cold water supply systems
Fusion instructions (summary)
- 1. Prepare fusion and check fittings.
- 2. Cut the pipe squarely.
- 3. Clean pipe ends of debris.
- 4. Measure and mark fusion depth.
- 5. Heat to the required temperature.
- 6. Join parts and allow to cool.
Technical specifications
- Model: THJ-110E
- Advertised pipe range (product title): 75–110 mm
- Data sheet pipe sizes: 20 mm, 25 mm, 32 mm
- Rated voltage: A.C. 220 V (110 V option available)
- Frequency: 50/60 Hz
- Power: 1200 W
- Working temperature: 260℃ ±3%
- Operating ambient temperature: -5 to 45 ℃
- Applicable materials: PP-R, PE, PB
- Net weight (machine): 2.0 kg
- Pieces per carton: 4
- Carton size (mm): 460 × 270 × 270
- Weight per carton: 20.8 kg
- Accessories: heating sockets, repair sockets and branch saddles (as per product sheet)
