Polymer electric fusion machine ZTHJ-110E

for industrial applicationsresistance

The ZTHJ-110E is a lightweight, portable PPR socket-fusion welding machine with a digital display, designed for plumbing and hot/cold water installations. It provides stable support and consistent heat transfer for reliable socket fusion joints.

Key features

• Stable square base and strong U-type machine support for improved stability during welding.
• Digital display and LED working light for accurate temperature monitoring and operation.
• Aluminium heater plate (thickness up to 19 mm) with optional Teflon surface; internal heating element available in 110V or 220V options.
• Lightweight, portable design (net weight 2.0 kg) with ABS + nylon handle and aluminium-moulded insulating cover.
• Magnesium cooling fins for heat dissipation and durable machine support.
• VDE copper wire with rubber-covered cable (up to 3 m), support for international plugs and protective plug cover.
• Includes heating sockets, repair sockets and saddle sockets; stainless steel spanner and screws supplied.

Included items and options

• Free spare parts included (check product page for conditions).
• OEM support: custom color, logo (engrave or sticker) and model finishes.
• Optional steel carrying box (1.0 mm); packing arranged for single or batch shipments.

Applications

• Plumbing and pipe installation work.
• Hot water supply systems.
• Cold water supply systems.
• Socket-fusion welding of PPR, PE and PB pipes and fittings.

Technical specifications

• Model: ZTHJ-110E
• Commercial range designation: 75–110 mm socket fusion
• Data-sheet pipe sizes (typical): 20 / 25 / 32 mm
• Rated voltage: A.C. 220 V
• Frequency: 50 / 60 Hz
• Power: 1200 W
• Working temperature: 260℃ ±3%
• Environment temperature: -5 to 45 ℃
• Applicable materials: PP-R, PE, PB
• Net weight: 2.0 kg
• Pcs per carton: 4
• Carton size (mm): 460 × 270 × 270
• Weight per carton: 20.8 kg
