Polymer electric fusion machine ZRJQ-125

for industrial applications

The ZRJQ-125 is a portable socket-fusion welding machine for controlled joining of PPR, PE and PB pipes from 75 to 125 mm, engineered for plumbing and hot/cold water distribution installations.

Key features

• Digital display for precise temperature control and readouts
• Teflon-coated heating plates and die heads option to reduce sticking and extend service life
• Robust aluminium heater plate (up to 19 mm thickness) with magnesium cooling fins
• Ergonomic ABS + nylon handle with nylon-rubber grip and LED work light
• VDE copper-core power cable with rubber sheath (3 m) and protective plug cover; supports worldwide plug options
• U-type support frame and special table clamps; stainless-steel spanner and screws included

Applications

• Plumbing and sanitary installations
• Hot and cold water supply systems
• Assembly of PPR, PE and PB pipe fittings

Usage instructions (summary)

• 1. Prepare machine and select correct heating die
• 2. Cut pipe square and remove burrs
• 3. Measure fusion depth on pipe and fitting
• 4. Set temperature/time on the digital display
• 5. Heat pipe and fitting for the specified time
• 6. Join parts and allow controlled cooling to form a permanent joint

Technical specifications

• Model: ZRJQ-125
• Rated voltage: 110V / 220V (options)
• Rated frequency: 50 Hz / 60 Hz
• Rated power: 1200 W
• Working temperature: 260 °C
• Temperature tolerance: ≤ 5 °C
• Warning (max) temperature: 295 °C
• Welding sizes: 75 mm, 90 mm, 110 mm, 125 mm
• Suitable materials: PP-R / PE / PB
• Net weight: 2.0 kg
• Pieces per carton: 2 pcs
• Gross weight (carton): 23.5 kg
• Packing box dimensions (mm): 460 × 270 × 270
• Heating element and die head: Teflon material (Teflon surface option)
• Heater plate material: aluminium (thickness up to 19 mm)
• Handle: ABS + strong nylon; nylon rubber grip
• Cooling fins: magnesium
• Standards & compliance: DVS2208-1; supports DVS and ASTM sizes
• Accessories: heating sockets, repair and saddle sockets; stainless-steel spanner and screws
• Box: steel box (1.0 mm); OEM color and logo options
• Certification & warranty: CE certificate available; 2-year quality warranty
