Polymer electric fusion machine THJ-32E

for industrial applications

The THJ-32E is a portable socket-fusion welding machine for PPR, PE and PB pipes, intended for plumbing and hot/cold water supply installations. It combines a square base for stability, an aluminium heating plate and a lightweight design for on-site use.

Key benefits

• 2-year quality warranty; spare parts provided.
• Square base for improved stability during welding.
• Lightweight and portable for on-site plumbing operations.
• Aluminium heating plate with optional Teflon coating for consistent heat transfer.

Applications

• Plumbing installation and repair
• Hot water supply systems
• Cold water supply systems

Data sheet

• Model: THJ-32E
• Pipe size (mm): 20, 25, 32
• Rated voltage: A.C. 220 V
• Frequency: 50/60 Hz
• Power: 650 W
• Working temperature: 260℃ ± 3%
• Ambient temperature: -5 to 45℃
• Applicable material: PP-R, PE, PB
• Net weight: 1.6 kg
• Pcs/carton: 10
• Carton size (mm): 450 x 400 x 500
• Weight/carton: 35 kg

Product features / construction

• Robust aluminium heater plate (up to 19 mm thickness); optional Teflon surface.
• Heating element options: 110 V or 220 V.
• ABS body with reinforced nylon handle, LED work light and digital display.
• Aluminium molded insulation cover and magnesium cooling fins for thermal management.
• Stable U-type machine support and special table clamps for secure mounting.
• Includes stainless steel spanner and screws; supports heating sockets, repair sockets and saddle sockets.
• VDE copper wire with rubber-covered cable (up to 3 m); supports international plugs and protective plug cover.
• Steel packing box (1.0 mm); OEM color and logo engraving/sticker supported.
