Industrial vacuum cleaner MTL301 AIREX

dryhazardous dustdust

Overview
The MTL301 AIREX is an ATEX 1/3D certified compressed-air industrial vacuum designed for safe extraction of combustible dusts in zone 20 (indoor) and zone 22 (outdoor). Compact and manoeuvrable, it operates without an electric motor using a multi-nozzle venturi pneumatic system.

Operation and filtration

• Multi-nozzle venturi system driven by compressed air (consumption indicated: 729 nl/min at 6 bar via 12 mm hose)
• Tangential air inlet creating a cyclonic effect to direct particles into the recovery tank and reduce filter clogging
• Antistatic polyester cartridge, class M, with PTFE treatment (filter area 6,000 cm²)
• Standard integrated HEPA H14 absolute filter (11,000 cm²): 99.995% efficiency down to 0.18 µm
• DUSTOP semi-automatic back-cleaning system with manual flap, allowing filter performance restoration during use without dust dispersion

Safety and ATEX compliance

• Compliant with the ATEX directive
• Marking: II 1/3D Ex h IIIC T80°C Da/Dc
• Suitable for explosive atmospheres and combustible, fine or hazardous dusts (e.g. silica, sugar, chemical or organic powders)
• Operation without an electric motor: suitable solution for explosive atmospheres

Design, handling and use

• Recovery tank capacity: 13 litres
• Total weight indicated: 30 kg (compact and manoeuvrable unit)
• Mounted on two large fixed wheels and two multidirectional castors with brake
• Dimensions indicated: 46 x 48 x 90 cm (alternative listing: 48 x 49 x 90 h)
• Particularly recommended for occasional or mobile interventions in ATEX zones, as a replacement or complement to centralised systems

Typical applications
Shipyards, electronics factories, industrial maintenance facilities, sensitive production areas and all interventions on combustible or hazardous dusts where operator safety and environmental protection are priorities.

Technical data / specifications

• Model: MTL301 AIREX
• Weight: 30 kg
• Dimensions: 46 x 48 x 90 cm (page also lists 48 x 49 x 90 h)
• Tank / capacity: 13 litres
• Maximum vacuum: 3 700 mmH₂O
• Maximum airflow: 150 m³/h
• Compressed air consumption: 729 nl/min at 6 bar (via 12 mm hose)
• Air inlet: 50 mm
• Cartridge filter area (antistatic polyester, class M): 6 000 cm²
• HEPA H14 absolute filter: 11 000 cm² — 99.995% efficiency down to 0.18 µm
• Noise level: 68 dB
• ATEX: zone 20 indoor / zone 22 outdoor, marking II 1/3D Ex h IIIC T80°C Da/Dc
• Clogging removal system: DUSTOP (semi-automatic, manual flap)
• Operation: without electric motor (pneumatic venturi)
• Wheels and castors: 2 large fixed wheels + 2 multidirectional castors with brake
