Cooling dry block heater Quick-Cal 560

doublecompact

Description
Quick-Cal 560 is an economical, compact and fast calibration furnace covering temperatures from -12°C (at ambient 20°C) to 140°C. It is intended for less demanding applications where larger furnaces or baths with lower uncertainties are not required. It is widely used in medical, sterilization and food industry applications.

The furnace is supplied with two interchangeable sleeves so that the calibrator does not need to be replaced when changing probe diameters. The low-temperature Quick-Cal 560 can operate from a small 12 V battery for portable calibration. When mains powered it accepts 100–240 V, 50/60 Hz.

The furnace includes one drilled sleeve with a 6.8 mm diameter well to 120 mm depth. Each of the two calibration cavities measures 13 mm diameter by 120 mm depth.

Key points

• Low-temperature operation: -12°C (at ambient 20°C) to 140°C
• Compact and fast operation

Specifications
Temperature range: -12°C (at ambient 20°C) to +140°C
Resolution: 0.1°C
Accuracy: ±0.1°C to ±0.4°C (comparison calibration); ±0.4°C (calibration versus sleeve display temperature in the standard 6.8 mm sleeve)
Stability: ±0.05°C
Rise time (0°C to 100°C): 9 min
Additional time for optimal stability: 5 min
Calibration volume: Two wells 13 mm × 120 mm depth

General specifications
Dimensions: 65 × 152 × 175 mm
Weight: 1.5 kg
Power: Switchable between 15 VDC or 100–240 VAC, 50/60 Hz; can operate from 12 V battery

Models and delivered items

• Quick-Cal 560-1: economical compact calibration furnace, -12°C (at ambient 20°C) to 140°C. Supplied as standard with: standard sleeve 1 × 6.8 mm × 120 mm depth, non-drilled sleeve, user manual, traceability certificate.
• Quick-Cal 560-2: economical compact calibration furnace, -12°C (at ambient 20°C) to 140°C. Supplied as standard with: standard sleeve 1 × 6.8 mm × 120 mm depth, non-drilled sleeve, user manual, traceability certificate.

Accessories

• 560-06-01a: Standard sleeve 1 × 6.8 mm × 120 mm depth
• 560-06-01b: Non-drilled sleeve
• 560-06-01c: Specific sleeve
• 935-14-98: Working Pt100 probe (temperature range: –50°C to +350°C)
• 931-22-71: Carry case
• 935-42-14: Rechargeable battery
• 935-42-19: Battery charger 220/240 V (50/60 Hz)
• 935-42-22: Battery charger 110/120 V (50/60 Hz)

Technical specifications

• Temperature range: -12°C (at ambient 20°C) to +140°C
• Resolution: 0.1°C
• Accuracy: ±0.1°C to ±0.4°C (comparison); ±0.4°C (sleeve display 6.8 mm)
• Stability: ±0.05°C
• Rise time 0→100°C: 9 minutes
• Additional time for optimal stability: 5 minutes
• Calibration volume: two wells Ø 13 mm × 120 mm depth
• Sleeves: two interchangeable sleeves (one drilled sleeve with 6.8 mm × 120 mm well)
• Dimensions: 65 × 152 × 175 mm
• Weight: 1.5 kg
• Power: 15 VDC or 100–240 VAC, 50/60 Hz; can operate from 12 V battery
