High-temperature dry block heater Fast-Cal High

coolingdigitalcompact

Overview
The Fast-Cal High is a portable industrial calibration furnace for temperature probes covering the range from 35°C to 650°C.

Available versions

• Model B (Basic): equipped with a controller displaying both setpoint and the temperature measured by the control probe.
• Model S (On-site): in addition to Model B features, includes a digital indicator to which a reference working probe (Pt100) can be connected to improve accuracy by removing temperature gradient and loading errors.
• Model S-TC (On-site with Thermocouple): similar to Model S but the working reference is a type N thermocouple.

Key points

• Temperature range: 35°C to 650°C.
• Calibration volume: 25 mm diameter x 148 mm depth.
• Compact and portable for on-site use.
• Easy to operate in the field.

Models and standard delivery contents
Fast-Cal High B

• Standard insert with 3 wells: 2 x Ø4.5 mm / 1 x Ø6.5 mm, depth: 140 mm.
• Cal NotePad software.
• Serial communication cable.
• Carrying case.
• User manual.
• Traceability certificate.

Fast-Cal High S

• Standard insert (2 x Ø4.5 mm / 1 x Ø6.5 mm, depth 140 mm).
• Cal NotePad software.
• Serial communication cable.
• Carrying case.
• User manual.
• Traceability certificate.
• Integrated digital indicator.
• Working reference Pt100 (reference: 935-14-72/DB).

Fast-Cal High S-TC

• Standard insert (2 x Ø4.5 mm / 1 x Ø6.5 mm, depth 140 mm).
• Cal NotePad software.
• Serial communication cable.
• Carrying case.
• User manual.
• Traceability certificate.
• Integrated digital indicator.
• Type N thermocouple working reference (reference: 935-14-63/DB).

Metal sleeves / Inserts

• 907-02-03d: Standard insert with 3 wells: 2 x Ø4.5 mm / 1 x Ø6.5 mm (depth: 140 mm).
• 907-02-03g: Un-drilled insert.
• 907-02-03f: Special insert.

Transport information
Dimensions without packaging: 228 x 248 x 143 mm
Weight without packaging: 6.35 kg

Software / Support
Associated software: CalNotePad (software for furnace and bath control).

Specifications / Technical data

• Temperature range: 35°C to +650°C.
• Stability: ±0.03°C to ±0.05°C.
• Basic accuracy: ±1°C up to 500°C.
• Total accuracy (with working reference): ±2°C up to 650°C.
• Heating time: 50°C to 650°C: 20 min.
• Cooling time: 650°C to 300°C: 20 min.
• Calibration volume: 25 mm diameter x 148 mm depth.
• Process input: 4-20 mA (on Sur Site model only).
• Overall dimensions: 228 x 248 x 143 mm.
• Mass: 6.35 kg.
• Power supply: 115 VAC or 230 VAC, 50/60 Hz — 750 Watts.
• Communication interfaces: RS232.
• Optional certificate: UKAS (5-point calibration certificate available).
