Thermogravimetric analyzer TGA1003

rubberprocessstability

Short description
Thermogravimetric analyzer (TGA) records sample mass change versus temperature or time to characterize thermal stability, composition and decomposition behavior. Intended for R&D, process optimisation and quality control in plastics, rubber, coatings, pharmaceuticals, catalysts, inorganic and metal materials, and composites.

Measurements and material characteristics

• Thermal stability and decomposition temperatures
• Decomposition processes and residue analysis
• Adsorption and desorption behaviour
• Oxidation and reduction reactions
• Quantitative composition analysis
• Influence of additives and fillers
• Moisture and volatile content
• Reaction kinetics

Structural features

• Furnace heated by double-row Ni–Cr alloy winding to reduce interference and provide high temperature resistance
• Sensor tray made of Ni–Cr alloy for improved high-temperature and corrosion resistance
• Separated power supply and heat-dissipation units to minimise thermal and vibration influence on the microbalance
• Open-top furnace design for easy operation and sample handling
• Host isolated by a water-zone constant-temperature device to stabilise chassis and microbalance
• Replaceable furnace module configurable to customer requirements

Controller and software features

• 32-bit ARM Cortex-M3 processor for fast sampling and processing
• 24-bit multi-channel ADC captures DSC, TG and temperature signals
• Independent control of power and water-circulation units to avoid mutual interference
• USB bidirectional communication enabling remote control, parameter setting and start/stop from PC
• 7-inch full-colour 24-bit touchscreen with on-screen TG calibration

Technical parameters

• Model: TGA1003
• Temperature range: RT – 1350°C
• Temperature resolution: 0.1°C
• Temperature stability: ±0.1°C
• Heating rate: 1 – 80°C/min
• Cooling rate (optional): 1 – 20°C/min
• Cooling time: 15 min (1000°C → 100°C)
• Balance measuring range: 1 mg – 2 g (extendable to 30 g)
• Sensitivity: 0.01 mg
• Constant temperature/time: 0 – 300 min (configurable)
• Display: 7" LCD full-colour touch screen
• Atmosphere modes: inert, oxidizing, reducing, static & dynamic
• Gas system: built-in mass flow meter with two-way switching and flow control
• Software: intelligent software for automatic TG curve recording, data processing and report printing
• Data interface: USB (special software, intermittent free upgrades)
• Power: AC 220V 50Hz
• Dimensions: 490 × 400 × 343 mm

Packing list

• Host – 1 set
• Software – 1 copy
• Power cord – 1 pc
• Data cable – 1 pc
• Sample crucibles – 100 pcs
• 10A fuse – 2 pcs
• Manual – 1 copy
• Gas tubing – 2 pcs
• Tweezers and sample spoon – 1 set

Technical specifications

• Model: TGA1003
• Temperature range: RT – 1350°C
• Resolution: 0.1°C; balance sensitivity 0.01 mg
• Heating rate: 1–80°C/min; optional cooling 1–20°C/min
• Balance range: 1 mg–2 g (extendable to 30 g)
• Display: 7" full-colour touch LCD
• Atmospheres: inert / oxidizing / reducing; static & dynamic modes
• Interface: USB; intelligent software for TG recording and processing
