3-axis CNC machining center Portalo C 3019

verticalwith moving tablegantry

Product summary
The Portalo C 3019 CNC gantry machine is a portal-type CNC machining center designed for precision machining of large, heavy workpieces. It combines a fixed gantry with a movable table to handle heavy cutting operations and high‑speed finishing of complex dies and molds. Standard equipment covers tool and workpiece measuring, chip removal and automated maintenance features.

Highlights

• Large working area and high table load capacity
• Rigid fixed gantry for heavy-duty machining
• 24-station quick-action tool changer
• Renishaw tool and workpiece measuring systems
• Siemens control and proven servo drive components

Product details
Portal

• Fixed gantry with a movable setup table enables machining of very large and heavy parts
• Combination of linear guides and box/flat ways ensures long service life, high rigidity and higher machining speeds
• Preloaded ball screws and Siemens servomotors provide dynamic feed and fast rapid traverse on all axes

Main spindle

• High drive power and a wide speed range guarantee torque reserves for heavy cutting tasks

Tool changer

• Robust 24-position tool changer with dual-arm gripper for flexible and rapid tool changes during production

Control

• Siemens 828D control with intuitive programming features; Siemens Shopmill software included

Equipment

• Large sliding doors for easy access to the working area
• Renishaw measuring systems for tool and workpiece gauging
• Powerful coolant system with chip conveyor
• Automatic central lubrication system for simplified maintenance

Technical specifications

• Working area — Table dimensions: 3000 mm x 1500 mm; Table load capacity (max.): 9000 kg; Spindle nose-to-table distance: 150 mm - 1050 mm; Column distance: 1900 mm.
• Travels — X-axis: 3100 mm; Y-axis: 1900 mm; Z-axis: 900 mm.
• Headstock — Spindle speed: 6000 1/min; Spindle mount: SK 50 ISO 7388-1 (DIN 69871); Spindle diameter: 190 mm.
• Rapid feed — X/Y: 12 m/min; Z: 10 m/min.
• Feed — Working feed: 8000 mm/min.
• Tooling — Tool stations: 24 positions (tool changer).
• Accuracies — Positioning accuracy: 0.005/300 mm; Repeatability: 0.005/1000 mm.
• Drive capacity — Main drive rating: 26 kW; Main drive continuous load: 22 kW.
• Dimensions and weight — Overall (L x W x H): 8.5 m x 4.3 m x 4.8 m; Weight: 22000 kg.
