3-axis CNC machining center Portalo C 4022 CNC
verticalwith moving tablegantry

3-axis CNC machining center - Portalo C 4022 CNC - Knuth Machine Tools - vertical / with moving table / gantry
3-axis CNC machining center - Portalo C 4022 CNC - Knuth Machine Tools - vertical / with moving table / gantry
3-axis CNC machining center - Portalo C 4022 CNC - Knuth Machine Tools - vertical / with moving table / gantry - image - 2
3-axis CNC machining center - Portalo C 4022 CNC - Knuth Machine Tools - vertical / with moving table / gantry - image - 3
3-axis CNC machining center - Portalo C 4022 CNC - Knuth Machine Tools - vertical / with moving table / gantry - image - 4
3-axis CNC machining center - Portalo C 4022 CNC - Knuth Machine Tools - vertical / with moving table / gantry - image - 5
Add to favorites
Compare this product
Go to the Knuth Machine Tools website for more information

Characteristics

Number of axes
3-axis
Spindle orientation
vertical
Structure
gantry, with moving table
Spindle mount
SK50
Number of tool stations
24 tools
Applications
heavy-duty, for large workpieces
Other characteristics
high-speed
X travel

4,200 mm
(165.35 in)

Y travel

2,500 mm
(98.43 in)

Z travel

1,000 mm
(39.37 in)

Rotational speed

6,000 rpm
(37,699 rad.min-1)

Power

26 kW
(35.35 hp)

Work feed X-axis

12 m/min

Work feed Y-axis

12 m/min

Work feed Z-axis

10 m/min

Table load capacity

10,000 kg
(22,046 lb)

Positioning accuracy

0.005 mm
(0.0002 in)

Repeatability

0.005 mm
(0.0002 in)

Weight

34,000 kg
(74,957.17 lb)

Overall length

10 m
(32'09" )

Overall width

5.1 m
(16'08" )

Overall height

4.9 m
(16'00" )

Description

Overview
The Portalo C 4022 CNC gantry vertical machining centre is built for precision machining of large, heavy workpieces. The fixed gantry and movable table layout supports heavy material removal as well as high‑speed finishing of complex dies and moulds. Modular standard equipment enables adaptation to production requirements.

Highlights
  • High table load capacity for heavy workpieces
  • Large machining envelope
  • Rigid fixed gantry construction
  • 24‑station quick‑action tool changer
  • Renishaw probing systems for tool and workpiece


Gantry
  • Extra‑rigid gantry and guide solutions designed for long travels and heavy cutting
  • Combination of linear guides and box ways for long life, higher speeds and sustained rigidity
  • Preloaded ball screws and Siemens servo motors deliver dynamic feed and fast rapid moves on all axes


Main spindle
  • High drive power and broad speed range provide torque reserves required for heavy‑duty cutting


Tool changer
  • Robust 24‑station changer with dual‑arm gripper for flexible, fast tool changes in production


Control
  • Siemens 828D control with intuitive programming and strong service support
  • Siemens Shopmill software included to simplify programming of complex contours


Equipment
  • Large sliding doors for easy access and loading
  • Renishaw systems for tool and workpiece measurement to reduce setup time and scrap
  • Powerful coolant system and chip conveyor for chip removal
  • Automatic central lubrication to simplify maintenance


Technical specifications
  • Table dimensions: 4.000 mm x 1.800 mm
  • Table load capacity (max.): 10.000 kg
  • Spindle nose-to-table distance: 200 mm - 1.200 mm
  • Column distance: 2.200 mm
  • Travel X-axis: 4.200 mm
  • Travel Y-axis: 2.500 mm
  • Travel Z-axis: 1.000 mm
  • Spindle speed: 6.000 1/min
  • Spindle mount: SK 50 ISO 7388-1 (DIN 69871)
  • Spindle diameter: 190 mm
  • X-axis rapid feed: 12 m/min
  • Y-axis rapid feed: 12 m/min
  • Z-axis rapid feed: 10 m/min
  • Work feed: 8.000 mm/min
  • Number of tool stations: 24 positions
  • Positioning accuracy: 0,005/300 mm
  • Repeatability: 0,005/1000 mm
  • Motor rating main drive: 26 kW
  • Main drive, continuous load: 22 kW
  • Overall dimensions (L x W x H): 10 m x 5,1 m x 4,9 m
  • Weight: 34.000 kg
