3-axis CNC machining center Portalo C 3022 CNC

verticalwith moving tablegantry

Product description
Machines of the Portalo C 3022 CNC series are designed for precision machining of large and heavy workpieces. The machine frame features a fixed gantry and a movable table, enabling heavy-duty material removal and high-speed finishing of complex dies and moulds. Standard and optional equipment allow configuration to specific production requirements.

Highlights

• High workpiece weight capacity
• Large machining area
• Rigid fixed gantry structure
• 24-position quick-action tool changer
• Renishaw measuring systems for tool and workpiece

Details
Gantry

• The large machining area and long travel distances require an extra-rigid gantry and robust guide solutions to meet stringent tolerances
• A combination of linear guides and box ways extends service life while enabling higher machining speeds and sustained rigidity
• Preloaded precision ball screws and proven Siemens servomotors deliver dynamic and rapid feeds on all axes

Main spindle

• High drive power and a wide speed range provide necessary torque reserves for heavy-duty machining operations

Tool Changer

• Robust 24-station tool changer with a dual-arm gripper ensures flexible and rapid tool changes during production

Control

• Siemens 828D control offers intuitive programming, comprehensive support and service
• Siemens Shopmill software included as standard to simplify programming of complex contours and workpieces

Equipment

• Large sliding doors on the machine enclosure for easy access and loading
• Renishaw tool and workpiece probing enhances efficiency by reducing downtime, minimizing setup errors and lowering scrap rates
• Powerful coolant system and integrated chip conveyor for reliable chip removal
• Automatic central lubrication simplifies routine maintenance

Technical specifications (excerpt)

• Table dimensions: 3,000 mm x 1,800 mm
• Table load capacity (max.): 10,000 kg
• Spindle nose-to-table distance: 200 mm – 1,200 mm
• Column distance: 2,200 mm
• Travels (X / Y / Z): 3,200 mm / 2,500 mm / 1,000 mm
• Spindle speed: 6,000 1/min
• Spindle mount: SK 50 ISO 7388-1 (DIN 69871)
• Spindle diameter: 190 mm
• Rapid feed (X / Y / Z): 12 / 12 / 10 m/min
• Working feed: up to 8,000 mm/min
• Tool stations: 24 positions
• Positioning accuracy: 0.005/300 mm
• Repeatability: 0.005/1000 mm
• Main drive rating: 26 kW (22 kW continuous)
• Overall dimensions (L x W x H): 8 m x 5.1 m x 4.9 m
• Weight: 30,000 kg
• Model: Portalo C 3022 CNC
