Chain sling masterlink Grade 100

Overview

• Powder-coated finish
• Design factor: 4:1
• Proof tested
• Embossed marking with grade and size
• Intended for single‑leg chain slings
• Can be used in choker or basket configurations
• Spare parts available

Parameter
Working Load Limit (Lbs.) | For Chain Size | e | t | w | d | s | Weight Ea.

• 4,300 | 9/32" | e: 3.6 | t: 2.76 | w: 1.34 | d: 0.35 | s: 0.35 | Weight: 0.62
• 5,700 | 5/16" | e: 3.58 | t: 2.76 | w: 1.34 | d: 0.39 | s: 0.35 | Weight: 0.66
• 8,800 | 3/8" | e: 5.04 | t: 4.02 | w: 1.97 | d: 0.49 | s: 0.47 | Weight: 1.54
• 15,000 | 1/2" | e: 6.65 | t: 5.35 | w: 2.6 | d: 0.63 | s: 0.59 | Weight: 3.09
• 22,600 | 5/8" | e: 8.43 | t: 6.77 | w: 3.27 | d: 0.79 | s: 0.69 | Weight: 6.04

Standards
Name: Grade 100 Clevis Master Link
Package: Carton + Steel Pallet

Caractéristiques / spécifications techniques

• Product: Clevis Master Link for Grade 100 chain applications
• Finish: Powder-coated
• Design factor: 4:1
• Test: Proof tested
• Marking: Embossed with grade and size
• Intended use: Single‑leg chain slings; suitable for choker or basket sling configurations
• Spare parts: Available
• Packaging: Carton and steel pallet
• Working load limits and dimensions (select examples):

  • 4,300 lbs — Chain size 9/32" — e: 3.6, t: 2.76, w: 1.34, d: 0.35, s: 0.35 — Weight: 0.62
  • 5,700 lbs — Chain size 5/16" — e: 3.58, t: 2.76, w: 1.34, d: 0.39, s: 0.35 — Weight: 0.66
  • 8,800 lbs — Chain size 3/8" — e: 5.04, t: 4.02, w: 1.97, d: 0.49, s: 0.47 — Weight: 1.54
  • 15,000 lbs — Chain size 1/2" — e: 6.65, t: 5.35, w: 2.6, d: 0.63, s: 0.59 — Weight: 3.09
  • 22,600 lbs — Chain size 5/8" — e: 8.43, t: 6.77, w: 3.27, d: 0.79, s: 0.69 — Weight: 6.04
