Hydraulic shear KHT V 4010 CNC

sheet metalguillotineCNC

Product overview
The KHT V 4010 CNC hydraulic guillotine shear is engineered for industrial plate cutting with high positional accuracy. A guided cutter bar with adjustable cutting angle reduces workpiece twist and rework. Touchscreen control automatically positions cutting gap, angle and length. The robust back gauge and stainless-steel-capable blades support demanding production environments. Optional accessories extend application flexibility.

Highlights

• Cybelec Touch 8 control
• Controlled back gauge with preloaded ball screw
• Controlled kerf adjustment
• Controlled cutting angle adjustment
• Blades suitable for stainless steel

Machine frame

• Very rigid, heavy welded frame, stress-relieved and machined to tight tolerances
• Frame machined on 5-axis equipment in a single setup for improved precision and life
• Load-bearing components designed with large radii to prevent cracking
• Table designed with lower cutter mount and cutter bar to minimize torsion and optimize load distribution
• Factory paint system: two coats, each ≥ 60 μm

Material support

• Large work table with roller balls and rigid lateral angular stop for safe plate alignment
• Long, sturdy front support arms for secure handling of large plates

Hydraulics

• Polished pistons (surface grade 2 μm) for extended seal life
• Cylinder bodies forged from high-strength SAE 1040 material
• Reliable, low-maintenance hydraulic system designed for easy service
• Hydraulically regulated hold-downs ensure steady fixation near the cut line

Back gauge and control

• User enters plate length, thickness and strength into the programmable control; kerf, cutting angle and length are automatically selected
• Robust back gauge system suited for heavy production environments
• Linear guides and preloaded ball screws mounted within protective enclosures

Equipment

• Electrical components from reputable manufacturers for high availability
• Upper knife with 2 edges and lower knife with 4 edges; blades suitable for stainless steel
• Foot pedal operation with emergency stop; pedal position adaptable to operator needs
• ECO mode available for reduced energy consumption

Safety

• Safety features comply with current CE regulations
• Rear-mounted light barrier protects the working area

Technical specifications

• Working area — Working length: 4.100 mm; Throat depth: 150 mm; Cutting angle: 0.5° - 2°; Strokes per minute: 8 H/min - 17 H/min; Hold-downs: 20 positions; Hold-down capacity: 32 t; Table size: 4.400 mm x 550 mm x 850 mm
• Back gauge — Rear stop: 1.000 mm; Feed speed X-axis: 9.000 mm/min
• Front support arms — Number: 3 positions; Length: 1.000 mm
• Cutting capacities — Plate thickness (max.) 450 N/mm²: 10 mm; 700 N/mm²: 6 mm
• Drive capacity — Motor rating main drive: 22 kW; Hydraulic tank volume: 200 l
• Measures and weights — Overall dimensions (L x W x H): 5,25 m x 3,6 m x 2,35 m; Weight: 15.000 kg
