Hydraulic shear KHT V 4020 CNC

sheet metalguillotineCNC

Description
The KHT V 4020 CNC hydraulic guillotine shears are heavy‑duty, CNC‑controlled plate shears engineered for high‑precision metal cutting in industrial production. A guided cutter bar with adjustable cutting angle minimises workpiece twist and reduces rework. The intuitive Cybelec touchscreen control automatically positions cutting gap, angle and length based on material parameters. Standard knives are rated for stainless steel and a robust, motorised back gauge ensures repeatable results. A wide range of standard and optional equipment adapts the machine to diverse production needs.

Highlights

• Cybelec Touch 8 touchscreen control (CybTouch 8 G)
• Motorised back gauge with preloaded ball screw
• CNC‑controlled blade gap and cutting angle adjustment
• Upper and lower knives suitable for stainless steel
• Energy‑saving ECO mode

Working area
Working length: 4.100 mm
Throat depth: 150 mm
Cutting angle: 0.5° – 2° (adjustable)
Strokes per minute: 4 H/min – 8 H/min
Hold‑down positions: 20
Hold‑down capacity: 32 t
Table size: 4.430 mm x 650 mm x 950 mm

Back Gauge
Rear stop: 1.000 mm
Feed speed X‑axis: 9.000 mm/min

Front Support Arms
Number of support arms: 3 positions (additional lengths optional)
Length of support arms: 1.000 mm

Cutting Capacities
Max plate thickness @ 450 N/mm²: 20 mm
Max plate thickness @ 700 N/mm²: 13 mm

Drive capacity
Main drive motor rating: 45 kW
Hydraulic tank volume: 500 l

Measures and weights
Overall dimensions (L x W x H): 5.7 m x 3.8 m x 2.85 m
Weight: 28,000 kg

Product Details
Machine Frame

• Very rigid, heavy welded frame stress‑relieved after welding
• Frame machined in one setup on 5‑axis milling machines for long‑term precision
• Load‑bearing parts designed with large radii to avoid crack formation
• Table with lower knife mount and cutter bar designed for minimal torsion and even load distribution
• All components finished in a modern paint/drying system (minimum two coats, ≥60 μm per coat)

Material Support

• Large worktable with roller balls and rigid lateral squaring stop for safe handling and alignment
• Long, sturdy support arms to support large plates

Hydraulics

• Polished pistons with superior surface finish (≈2 μm) for long seal life
• Cylinder bodies forged from high‑strength SAE 1040 material
• Reliable, low‑maintenance hydraulic system designed for easy service
• Hydraulically regulated hold‑downs secure the sheet close to the cut line

Back Gauge and Control

• Programmable control calculates optimal kerf, cutting angle and length from material input (thickness, strength, length)
• Robust back gauge suitable for harsh production environments
• Linear guides and preloaded ball screws installed in protective housings

Equipment

• Electrical components from reputable manufacturers for high availability
• Upper knife with 2 cutting edges and lower knife with 4 cutting edges (stainless steel capable)
• Foot pedal operation with emergency stop (flexible pedal position)
• ECO mode for energy saving (automatic pump stop after prolonged idle)

Safety

• Safety features compliant with current CE regulations
• Rear light‑barrier system protecting the work area

Standard Equipment

• Cybelec Touch 8 G controller (intuitive HMI, automated material parameter calculation, EasyCut page, program storage)
• Energy saving function (ECO mode)
• CNC‑controlled blade gap adjustment
• Motorised back gauge
• Shadow‑graph display of cut line
• Material support table with rollers
• Support arms (3 positions)
• Lateral stop
• Foot switch with emergency stop
• Finger guard
• Safety system for work area and back gauging
• Standard upper and lower knives suitable for stainless steel
• Operating manual

Optional Equipment (examples)

• Support arm L = 1,500 mm for KHT V CNC
• Support arm L = 2,000 mm for KHT V CNC
• Squaring arm L = 1,500 mm
• Squaring arm L = 2,000 mm
• Adjustable angle stop 0–180°
• Automatic central lubrication system
• Hydraulic oil cooler
• Sheet hold‑up device (fixed) for certain machine lengths

Technical specifications

• Model: KHT V 4020 CNC
• Working length: 4.100 mm
• Throat depth: 150 mm
• Cutting angle: 0.5° – 2° (adjustable)
• Strokes: 4 – 8 H/min
• Hold‑down positions: 20
• Hold‑down capacity: 32 t
• Table size: 4.430 mm x 650 mm x 950 mm
• Back gauge rear stop: 1.000 mm; feed speed X‑axis: 9.000 mm/min
• Support arms: 3 positions; length 1.000 mm (options 1.500 / 2.000 mm)
• Max plate thickness: 20 mm @ 450 N/mm²; 13 mm @ 700 N/mm²
• Main drive motor: 45 kW
• Hydraulic tank volume: 500 l
• Overall dimensions (L x W x H): 5.7 m x 3.8 m x 2.85 m
• Weight: 28,000 kg
