3-roller plate bending machine KRM T 10/4,0

electricconicalasymmetrical

Description The KRM T 10/4,0 is a 3‑roll plate roller designed for medium-capacity forming of sheet metal up to 1,050 mm working length. Built on a solid closed frame, it supports manual rear-roll adjustment as standard with an optional motorised rear roll. The machine handles conical bending and features hardened rolls with wire insertion grooves suitable for a range of steel grades.

Highlights

• Asymmetric 3‑roll layout for improved forming accuracy
• Main motor with braking for precise starts/stops
• Hardened rolls with wire insertion grooves Ø 4/7/9/13 mm
• Conical bending function included
• Manual rear roll adjustment (motorised option available)

Technical specifications

• Model: KRM T 10/4,0
• Working length: 1,050 mm
• Max plate thickness (450 N/mm²): 4 mm
• Max plate thickness (700 N/mm²): 2 mm
• Max thickness for conical bending (steel): 3 mm
• Roll diameter: 110 mm
• Roller speed: 3 m/min
• Drive motor (main): 2.2 kW
• Roll grooves: Ø 4 / 7 / 9 / 13 mm
• Overall dimensions (L×W×H): 2.2 m × 0.75 m × 1 m
• Weight: 990 kg
