Conventional lathe Sinus 400/3000 D

horizontal2-axisuniversal

Description
Sinus 400/3000 D is a conventional universal lathe built on a heavy one-piece cast bed. Designed for machining long shafts and large flanges, it combines classic mechanical drive elements with integrated functions — removable bed bridge, rapid traverses and a taper-turning device — to support flexible production workflows.

Highlights

• One-piece heavy cast bed for high rigidity
• Large spindle bore (105 mm) for long shafts and pipes
• Mechanical multi-plate clutch for controlled spindle start-up
• Rapid traverse on X and Z axes to reduce non-productive time
• Taper turning device included for external and internal tapers

Machine bed

• Heavy, single-piece cast base frame to minimise vibration
• Induction-hardened and ground guideways (›HB 400) for durable accuracy

Headstock and drive

• Designed for precision and smooth running under load
• Spindle bore 105 mm, spindle mount D1-8, spindle taper ø113 mm / 1:20
• Mechanical multi-disc clutch provides smooth acceleration of heavy workpieces

Support

• Support movable in rapid traverse longitudinally and transversely to cut auxiliary times
• Integrated overload protection for feed shaft and lead screw
• Lead screw covered to reduce wear from chips and contamination

Tailstock

• Tailstock quill with robust, easy-to-read scale
• Long quill stroke for demanding drilling and centring operations
• Side adjustment for turning conical shafts between centres

Equipment and accessories

• Centralised lubrication on the support for simplified maintenance
• Taper turning device and quick-change tool holder system included as standard
• Fixed and travelling steady rests supplied for long workpieces
• LED lighting, large rear splash guard, coolant system and operating tools included

Technical specifications

• Max. workpiece length: 3,000 mm
• Turning diameter over bed: 800 mm
• Turning Ø over support: 570 mm
• Turning diameter without gap bridge: 1,035 mm
• Gap bridge length: 330 mm
• Bed width: 400 mm
• X travel: 420 mm
• Z1 travel: 230 mm
• Top slide swing: 70°
• Spindle speed: 25 – 1,600 1/min
• Spindle bore: 105 mm
• Spindle mount: D1-8
• Spindle taper: ø113 mm / 1:20
• Rapid feed X/Z: 2,000 / 4,000 mm/min
• Feed X: 0.022 – 0.74 mm/rev
• Feed Z: 0.044 – 1.48 mm/rev
• Threading ranges: Metric 0.45 – 120 mm; Diametral 0.88 – 160 DP; Module 0.25 – 60 mm; Whitworth (54) 7/16 – 80 TPI
• Tailstock quill Ø: 90 mm, quill stroke: 235 mm, taper: MT 5
• Main drive power: 7.5 kW
• Overall dimensions (L x W x H): 4.74 m x 1.14 m x 1.91 m
• Weight: 3,870 kg
