Data connector AKS300B-240Acircularcrimpthrough-hole
Add to favorites
Compare this product
Characteristics
- Type
- data
- Shape
- circular
- Connection type
- crimp, through-hole
- Product applications
- sleeve, strip, edge
- Other characteristics
- flexible, bi-metal
Description
Used for splicing Al conductors and Cu conductors
Stranded/solid Al conductors, stranded/flexible Cu conductors.
For multi-stranded Cu conductors, contact crimping using the Dual system is recommended.
Two crimps are needed for Al.
AlCu through connector for stranded/solid Al cable 300 mm² to stranded/flexible Cu cable 240 mm². When crimping the Cu section, place the dies between the mark on the sleeve and the edge of the Cu section. Used with Elpress certified systems V1300, V250.
s1 (mm): 40
d (mm): 22.3
D (mm): 37
L (mm): 126.5
d1 (mm): 22.5
D1 (mm): 29
s (mm) - strip length: 68
AWG/MCM Stranded Al: 550 MCM
AWG/MCM Cu: 450 MCM
mm² Stranded Al: 300
mm² Cu: 240
