Quick-disconnect solderless terminal KRX10-8tubularnon-insulatedcopper
Add to favorites
Compare this product
Characteristics
- Connection type
- quick-disconnect
- Configuration
- tubular
- Insulation
- non-insulated
- Material
- copper
Description
Material: Cu 99.95%, tin plated Cu/Sn.
Mounted pull-strain relieved.
Uninsulated tube terminal for Cu conductors 10 mm² solid (Excel) with an M8 hole in the palm. Used with Elpress certified systems V600, V1300, V250.
W (mm): 22
N (mm): 8.5
N1 (mm): 17.5
P (mm): 26
t (mm) - palm thickness: 3.5
s (mm) - strip length: 30
Screw: M8
AWG/MCM Cu: 8 AWG
mm² Cu: 10
