Multitouch screen panel PC W07IE3S-PPT1

PCAP capacitive touch screen7"1024 x 600

Overview
The Winmate W07IE3S-PPT1 is a 7-inch PP Series HMI Panel PC powered by the Intel® Celeron® N6211 (Elkhart Lake). It is engineered for machine control, factory automation and operator interfaces in industrial environments, featuring a true-flat design, PCAP multi-touch display, front IP65 protection and a fanless low-power architecture.

Key features

• 7" (1024 x 600) display with Projected Capacitive (PCAP) multi-touch
• Intel® Celeron® N6211 processor (up to 3.0 GHz)
• Front IP65 rating for dust and splash protection
• Dual Intel® Ethernet controllers (2 x 2.5 Gbps)
• Fanless cooling and ultra-low power consumption
• Rich I/O and M.2 expansion for flexible connectivity

Product highlights
The PP Series provides a slim, true-flat front panel for easy cleaning and hygienic use. PCAP multi-touch enables accurate on-screen operation for operator stations. Front IP65 ensures protection in harsh industrial conditions. Optional aluminum die-cast housing and metal back cover increase mechanical durability. Multiple I/O (serial, USB, LAN, audio, optional HDMI) and expansion slots (M.2) support IoT integration and system expansion.

Certifications
CE, FCC

Technical specifications

• Display: 7.0 inches, 1024 x 600, Projected Capacitive Multi Touch
• Panel brightness: 320 nits; Contrast ratio: 1000:1; View angles: 75/75/75/70; Active area: 153.6 x 90 mm
• Processor: Intel® Celeron® N6211 (up to 3.0 GHz)
• Memory: 4 GB (default); 8 GB / 16 GB (optional)
• Storage: 128 GB SSD (default); 256/512 GB / 1 TB / 2 TB optional; 1 x SATA III for 2.5" SSD/HDD (optional)
• Ethernet: 2 x Intel® Ethernet Controller (2 x 2.5 Giga LAN RJ45)
• Security: TPM 2.0
• OS (optional): Windows 11 IoT Enterprise 64-bit; Windows 11 Pro 64-bit; Windows 10 IoT Enterprise 64-bit; Linux Ubuntu 22.04
• WLAN / Bluetooth: optional (M.2 2230 E-Key)
• USB: 2 x USB3.2 Gen2x1 (Type-A)
• Serial: 1 x RS232/422/485 (default RS232) + 1 x RS232
• Video: 1 x HDMI 2.0 (optional)
• Audio: 2 x speaker
• Expansion: 1 x M.2 2242 B-Key (SATA III SSD); 1 x M.2 2230 E-Key (Wi‑Fi)
• Indicators: LED for power, LED for storage
• Power input: 1 x 12V DC (2.5φ DC jack); Adapter: 12V 50W (accessory)
• Mechanical: Dimensions 185 x 128 x 61 mm; Cut-out 175 x 117 mm; Weight 1.5 kg
• Mounting: Panel mount (default); VESA mount optional
• Enclosure: Plastic front bezel with metal back cover (aluminum die-cast option)
• Cooling: Fanless design
• Environment: Operating humidity 10%–90% RH non‑condensing; Operating temperature 0°C–50°C; Storage temperature -10°C–60°C
• IP rating: Front IP65
• Certification: CE, FCC
• Accessories: 100~240V AC to DC adapter; power cord; VESA screws; mounting clips
