Disc brake caliper DS 230 FEMmanualspringelectro-hydraulic release
Add to favorites
Compare this product
Characteristics
- Type
- disc
- Operation
- spring, manual, electro-hydraulic release
- Other characteristics
- adjustable, applications
- Torque
Min.: 250 Nm
(184.390537 ft.lb)Max.: 1,600 Nm
(1,180.099439 ft.lb)- Braking force
2,750 N, 4,100 N, 8,250 N, 9,700 N
- Power
130 W, 180 W, 240 W, 280 W
Description
Product
Brake caliper DS 230 FEM - spring-applied, electrohydraulic release; manual wear adjustment; designed for 30 mm brake discs and industrial applications.
Documents available
Features
Technical specifications
Brake caliper DS 230 FEM - spring-applied, electrohydraulic release; manual wear adjustment; designed for 30 mm brake discs and industrial applications.
Documents available
- Datasheet DS 230 FEM (PDF)
- Flyer Disc Brake DS (PDF)
- 3D CAD models (ZIP)
- Installation instructions DS XXX FEM-FEA (PDF)
- Catalogue Industrial Brakes (PDF)
Features
- Product code: D (Brake caliper)
- Brake type: S (Disc brake)
- Frame size: 230
- Activation: Spring-applied (F)
- Release: Electrohydraulic (E)
- Manual wear adjustment: Yes (M)
- Compatible thrustors: 451, 452, 453, 454
- Thrustor mounting: right (R) or left (L)
- Brake disc thickness: 30 mm
Technical specifications
- Type: Brake caliper / disc brake
- Model: DS 230 FEM
- Frame size: 230
- Activation: Spring-applied
- Release: Electrohydraulic
- Manual wear adjustment: Yes
- Compatible thrustors: 451–454
- Thrustor mounting: right or left
- Brake disc thickness: 30 mm
