Disc brake caliper DS 370 FEMspring activatedelectro-hydraulic releasefor motors
Add to favorites
Compare this product
Characteristics
- Type
- disc
- Operation
- spring activated, electro-hydraulic release
- Other characteristics
- for cranes, for conveyor, winch, for motors
- Torque
Max.: 22,400 Nm
(16,521.392144 ft.lb)Min.: 2,950 Nm
(2,175.80834 ft.lb)- Braking force
20,100 N, 33,850 N, 50,000 N
- Power
370 W, 590 W, 680 W
Description
Product overview
Brake caliper DS 370 FEM, spring-activated and electrohydraulically released, designed for industrial disc brake applications. Frame size 370; compatible with 30 mm brake disc thickness.
Applications
Documents available
Key characteristics
Notes
3D CAD models (STEP) and technical documentation are available to support selection and installation.
Technical specifications
Brake caliper DS 370 FEM, spring-activated and electrohydraulically released, designed for industrial disc brake applications. Frame size 370; compatible with 30 mm brake disc thickness.
Applications
- Industrial machinery and rotating equipment (cranes, winches, conveyors, motors)
Documents available
- Datasheet DS 370 FEM
- Flyer Disc Brake DS
- Installation instructions DS XXX FEM-FEA
- Catalogue Industrial Brakes (P46)
- 3D CAD models (STEP)
Key characteristics
- Product: Brake Caliper — Code: D
- Disc Brake — Code: S
- Frame size: 370 — Code: 370
- Spring activated — Code: F
- Electrohydraulically released — Code: E
- Manual adjustment for friction block wear — Code: M
- Selectable thrustors: 455, 456, 457
- Thrustor mounting: right (R) or left (L)
- Brake disc thickness: 30 mm
Notes
3D CAD models (STEP) and technical documentation are available to support selection and installation.
Technical specifications
- Model: DS 370 FEM
- Type: spring activated, electrohydraulically released brake caliper
- Frame size: 370
- Brake disc thickness: 30 mm
- Manual adjustment for friction block wear
- Selectable thrustors: 455, 456, 457
- Thrustor mounting: right or left
- 3D CAD (STEP) models available
